User Manual for Microsemi PD-9006G Power over Ethernet Midspan Click to enlarge the picture
Contents of the user manual for the Microsemi PD-9006G Power over Ethernet Midspan
- Product category: Power over Ethernet (PoE) Microsemi
- Brand: Microsemi
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Microsemi Power over Ethernet (PoE)
|
User manual for the Microsemi PD-9006G Power over Ethernet Midspan contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Microsemi product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Microsemi user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Microsemi product will considerably shorten its lifespan!
|
Product description With support for both the 802.3at and 802.3af PoE standards, the PD-9006G Power over Ethernet Midspan from Microsemi is capable of powering a variety of different PoE-compliant devices, including access points, PTZ cameras, dome cameras, IP videophones, thin clients, and other PoE devices. This midspan is designed to work with existing network infrastructure while adding power to the network, eliminating the need for standalone power adapters for power-hungry components. Installation is simple with plug-and-play compatibility. With both Cisco and legacy PoE support, this midspan will be compatible with a wide variety of pre-existing networks. -
- High power over 2-pairs–30W per port
- Power redundancy - Mutual midspan-to-midspan backup
- PowerView Pro - Cloud-based SNMPv3 power management platform lets you access and manage Ethernet-based devices from the convenience of your desk
- Safe & reliable power over existing Ethernet infrastructure
- Cisco and legacy PoE support
- Plug-and-play installation
- Guaranteed system up-time
UPC: 844117001167 In the Box Microsemi PD-9006G Power over Ethernet Midspan (6 Ports) Limited Lifetime Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Microsemi PD-9006G Power over Ethernet Midspan in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMicrosemi PD-9006G/ACDC/M Specs | Ports | 6 | | Pass Through Data Rates | 10/100/1000 Mbps | | Power Over Ethernet | Output
Pin Assignment and Polarity: 4/5 (+), 7/8 (-)
Output Power Voltage: 55 VDC
User Port Power: 36 Watts (typical)
Input Power Requirements
AC Input Voltage: 100 to 240 VAC
DC Input: 55 V (RPS or another 9000 midspan)
AC Input Current
450 W Units: 5.5 A @ 110 VAC; 2.75 A @ 220 VAC
1000 W Units: 12 A @ 110 VAC; 6 A @ 220 VAC
AC Frequency
50 to 60 Hz
| | Indicators | System Indicator
AC Power (Green)
User Indicator
Channel Power (Green)
| | Connectors | PoE Ports and Management Port
Shielded RJ-45, EIA 568A and 568B
Console Port
USB Type-B
DC Connector
DC block terminal
RPS Com Connector
HD-D-sub-15
| | Management | PowerView Pro standard | | Environmental | Operating Ambient Temperature
32 to 104ºF (0 to 40ºC)
Operating Humidity
10 to 90%, non-condensing
Storage Temperature
-4 to 158ºF (-20 to 70ºC)
Storage Humidity
5 to 95%, non-condensing
Operating Altitude
-1000 to 10,000 ft (-304.8 to 3048 m) | | Certification and Compliance | IEEE 802.3af (PoE, PoH Type 1)
RoHS Compliant
CE
FCC Part 15, Class B
EN 55022 Class B (Emissions)
EN 55024 (Immunity), VCCI
UL/cUL Per EN 60950-1
GS Mark Per EN 60950-1
| | Dimensions | 17.3 x 10.8 x 1.75" (43.8 x 27.2 x 4.4 cm) | | Rack Units | 1 RU | | Weight | 14.3 lb (6.5 kg) | | | | Package Weight | 11.5 lb | | Box Dimensions (LxWxH) | 21.6 x 14.5 x 4.0" |
