Product description The Microsemi PD-9600G 6-Port 95W Gigabit PoH/PoE Midspan is designed to power network devices such as IP cameras, access control systems, thin clients, and other Ethernet powered devices that require up to 72W. It can also be used operate high-power-over-Ethernet infrastructure such as digital signage and monitors. This midspan is PoH compliant (Power Over HDBaseT) and can deliver power over all 4 pairs of the CAT 5E or better cable. It is also backwards compatible to 802.3af and 802.3at, including 4-pairs 802.3at. - Offers power over 4-pairs with 95W per port
- PoH compliant with 3-event classification
- PowerView Pro secure, remote SNMPv3 web-based management
- Supports both IPv4 and IPv6 addressing
- Plug-and-play installation
UPC: 844117001440 In the Box Microsemi PD-9600G 6-Port 95W Gigabit PoH/PoE Midspan Limited Lifetime Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Microsemi PD-9600G 6-Port 95W Gigabit PoH PoE Midspan in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMicrosemi PD-9606G/ACDC/M Specs | Number of Ports | 6 | | Pass Through Data Rates | 10/100/1000 Mb/s | | Power Over Ethernet | Pin Assignment and Polarity: Data Pairs 1/2 (-) and 3/6 (+), Spare Pairs 7/8 (-) and 4/5 (+)
Output Power Voltage: 54 to 57 VDC
User Port Power: 95 W
Aggregate Power: 1000 W | | Input Power | AC Input Voltage: 100 to 240 VAC
DC Input: 57 V (another 9600G midspan)
1000 W Unit: AC Input Current: 12 A @ 110 VAC; 6 A @ 220 VAC 50/60 Hz | | Management | PowerView Pro included | | Indicators | System Indicator: AC Power (Green)
Channel Power Indicators: Green - Power supplied over data and spare
Yellow - Power delivered over data or spare pairs | | Connectors | PoE ports and management Port: Shielded RJ-45, EIA 568A and 568B
Console Port: USB Connector Type B
DC Connector: DC Block Terminal
Com Connector: HD-D-sub-15 | | Regulatory Compliance | IEEE 802.3af (PoE, PoH Type1), IEEE 802.3at (PoE+ including 2-event, PoH Type 2), PoH Twin Type 3, RoHS Compliant, VCCI, CE, C-Tick | | Electromagnetic Emissions & Immunity | FCC Part 15, Class B, EN 55022 Class B (Emissions), EN 55024 (Immunity), VCCI | | Safety Approvals | UL/cUL Per EN 60950-1, GS Mark Per EN 60950-1 | | Operating Temperature | 32 to 104°F (0 to 40°C) | | Storage Temperature | -4 to 158°F (-20 to 70°C) | | Operating Humidity | 10 to 90%, non-condensing | | Storage Humidity | 5 to 95%, non-condensing | | Operating Altitude | -1000 to 10000' (-304.8 to 3048 m) | | Dimensions (W x H x L) | 1U, 17.3 x 10.8 x 1.7" (43.8 x 27.2 x 4.4 cm) | | Weight | 14.3 lb (6.5 kg) |
