Product description The HDR-9X from Middle Atlantic is the Horizontal Distribution Rack, which features a 4 rack-unit upper bay with a 100º pivoting top for patch panel mounting. A lower bay, which pivots 15º for access to rear connections, has an 18" usable component depth, and is provided to mount switches, hubs, and routers.
The HDR-9X includes a 2-gang electrical box. A 7 x 4" cable management pass-through and abundant cable tie points is included, along with a 24" length of hook and loop fasteners. Additionally, 4" cable duct knockouts are located on the top, bottom, and sides for electrical connections.
The HDR includes a rack-rail, which is constructed of 11-gauge steel and features tapped 10-32 mounting holes. Furthermore, the HDR distribution rack has a vented, beveled locking front door with flanges, for mounting in non-secure areas. - Provides two independent mounting areas for patch panels, switches, hubs and routers
- Upper bay mounts patch panels and pivots 100º with positive stop for punch-downs
- Standard 10-32 threaded rack-rail in both sections (2 spaces each)
- Lower bay mounts switches, hubs and routers and pivot 15º for access to rear connections
- Beveled front door with flanges on all sides for security
- UL Listed in the US and Canada (when used with the optional bonding kit, model # PET-K_HDR)
- Integral electrical box for power distribution
- Vented, locking front door for mounting in non-secure areas
- Multiple electrical knockouts to accommodate electrical conduit and Wiremold 4000 series raceway
- Abundant cable tie points and 24" length of hook and loop fasteners included for cable management
UPC: 656747216718 In the Box Middle Atlantic HDR Series Rack, HDR-9X Limited Lifetime Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Middle Atlantic HDR Series Rack, HDR-9X in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMiddle Atlantic HDR-9X Specs | Application/Usage | Patch Panel | | Rack Bays | 2 | | | | Compliance and Certification | EIA Compliant 19" distribution rack
Green Compliant: GreenGuard Gold
RoHS
EIA / TIA Compliant
ISO 9001 and ISO 14001 registered company | | | | Color / Finish | Putty powder coat | | Material | 16-Gauge steel | | Weight Capacity | 150 lb (68 kg) | | Dimensions (H x W x D) | 42.0 x 25.6 x 10.0" (1067 x 650 x 254 m) | | | | Package Weight | 65.2 lb | | Box Dimensions (LxWxH) | 43.0 x 27.0 x 13.0" |
