User Manual for Middle Atlantic Multi-Mount Universal DC Power Distribution Unit for Small to Medium Devices Click to enlarge the picture
Contents of the user manual for the Middle Atlantic Multi-Mount Universal DC Power
- Product category: Cable & Power Management Middle Atlantic
- Brand: Middle Atlantic
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Middle Atlantic Cable & Power Management
|
User manual for the Middle Atlantic Multi-Mount Universal DC Power contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Middle Atlantic product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Middle Atlantic user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Middle Atlantic product will considerably shorten its lifespan!
|
Product description Provided by third party: Eliminate wall warts and other power clutter in your AV, networking or security installations with DC power distribution, the perfect universal power solution for most DC powered devices like extenders, scalers, converters, and media players. With flexible mounting options, DC power distribution can be placed within typical rack units, small enclosures or wall boxes. This space-saving solution is intuitive to install with a color-coded screw terminal connector platform and polarity labeling. Utilize DC power distribution to streamline your install by allowing leads to be trimmed to length and by reducing design modifications contributing to additional labor costs.
- Key Features
-
- Multiple voltage outputs of 5 V, 12 V, 18 V, and 24 V supported in a single box form factor
- Color-coded screw terminal connectors with industry standard voltages and polarity labeling for easy identification
- Reliable multi-level protection on both AC input and DC outputs
- USB ports provided to conveniently power compatible products
- LED indicator lights show activity on each output and alert maximum capacity on each voltage bank
Table of Contents
|
Upload User Manual
Have you got an user manual for the Middle Atlantic Multi-Mount Universal DC Power Distribution Unit for Small to Medium Devices in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMiddle Atlantic PD-DC-125R Specs | | | Device Type | Power distribution unit - external | | Cord Length | 6 ft | | | | Input Voltage | 120 V | | Input voltage range | AC 100 - 132 V | | Frequency Required | 60 Hz | | Input Connectors | 1 x power IEC 60320 C14 | | Power Output Connectors Details | 6 x screw terminal - 5 V - 3 A
6 x screw terminal - 12 V - 2 A
6 x screw terminal - 18 V - 2.5 A
6 x screw terminal - 24 V - 1.2 A
4 x 4 pin USB Type A - 5 V - 2.5 A | | Output Voltage | 5 / 12 / 18 / 24 V | | Max Electric Current | 11.2 A | | Power Capacity | 600 Watt | | Surge Suppression | Yes | | Clamping Level | 595 V | | Circuit Protection | Circuit breaker | | | | Cables Included | Power cable - external - 6 ft | | Features | Built-in cooling fan, color-coded, LED indicators, overload protection, temperature controlled fan, Metal Oxide Varistor Technology (MOV) | | Compliant Standards | FCC Class B certified, ISO 9001, ISO 14001, UL 60950-1, cULus, CAN/CSA C22.2 No. 60950-1, RoHS 2011/65/EU | | | | Service & Support | Limited warranty - parts and labor - 3 years | | | | Width | 16.1 in | | Depth | 7.2 in | | Height | 1.7 in | | | | Box Dimensions (LxWxH) | 23.5 x 15.25 x 5.25" |
