User Manual for Minox 10x42 BV TAC Binocular Click to enlarge the picture
Contents of the user manual for the Minox 10x42 BV TAC Binocular
- Product category: Binoculars Minox
- Brand: Minox
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Minox Binoculars
|
User manual for the Minox 10x42 BV TAC Binocular contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Minox product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Minox user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Minox product will considerably shorten its lifespan!
|
Product description The B&H Binocular Buying Guide Read More The Minox 10x42 BV TAC Binocular combines the optical performance required for use while hunting, birding, or enjoying a game with a precision mil-based reticle that helps you range and estimate target size, or function as a spotter to assist in determining hold-over/under. The 42mm objectives straddle a fine line between size and weight to give the binocular competent low-light performance without weighing you down or being too bulky. Anti-reflection multi-coatings on all optical surfaces and phase-correcting prism coatings work together to produce high-contrast images that are bright and clear with accurate color rendition. A wide 65° apparent angle of view helps to minimize the image shake common to 10x magnifications to provide an immersive viewing experience, while its minimum focus distance comes in at less than four feet so you can make detailed observations on feeding birds or butterflies with ease.Designed to withstand the rigors of a life lived outdoors, the chassis is constructed of a lightweight and durable aluminum alloy. A black, rubberized armor covers the chassis to help give you a slip-resistant grip - especially in cold or wet conditions, while providing protection from bumps and impacts. The optical tubes are nitrogen-filled and O-ring sealed for fogproof performance when moving through extreme temperature variations, while also making it waterproof to a depth of 16 feet. For long-duration glassing sessions, the BV TAC is tripod mountable with an optional adapter, and twist-up eyecups ensure the perfect eye relief with or without eyewear. - Optical Performance
-
- 10x magnification
- 42mm objective lenses
- Compact roof prism optical path
- M* anti-reflection fully multi-coated optics produce accurate color fidelity, and improves contrast and image brightness
- Phase-corrected prisms improve color fidelity and contrast
- 343' field of view at 1000 yards
- Wide 65° apparent field of view
- Close focus distance: 4 feet
- Reticle Details
-
- Use the various markings for ranging, hold-over/under, and target size estimation
- Modified crosshair-style Mil ranging reticle
- Thin hairs on horizontal, and lower vertical axes
- Short 1 mil-long upper vertical hair leaves upper portion of reticle open
- Dot/Stadia combo denote every 1 mil with stadia marking every 1/2 mil, and hash-marks every 1/10 mil
- Use and Handling
-
- Closed-bridge configuration
- Large knurled center focus wheel
- ±4 right dioptric correction
- Twist-up rubber eyecups for use with or without eyewear
- 15mm eye relief
- Comfortable 4.2mm exit pupil
- Construction Details
-
- Lightweight and durable aluminum alloy chassis
- Rubberized armoring for a secure grip and protection against bumps and impacts
- Nitrogen-filled, fogproof and waterproof to 16' (5 m)
- Broad 14 to 122°F (-10 to 50°C) operating temperature range
- Weight: 27.5 ounces
In the Box Minox 10x42 BV TAC Binocular (MIL Ranging Reticle) Neck Strap Carrying Case Ocular Rainguard Limited 30-Year Warranty with Registration Summer Binocular Buying Guide Christopher Witt 07/14/2016 A Guide to Marine Binoculars Todd Vorenkamp 06/25/2015 Pentax Sport Optics Binocular Roundup Joseph Albanese 06/24/2015 A Guide to Birding with Binoculars Todd Vorenkamp 06/16/2015 User Manual PDF 450.4kb Table of Contents
|
Upload User Manual
Have you got an user manual for the Minox 10x42 BV TAC Binocular in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMinox 62053 Specs | Prism Type | Roof | | Magnification | 10 x | | Objective Lens Diameter | 42 mm | | Angle of View | 6.5° (Actual) | | Field of View | 341.2' @ 1000 yd / 113.7 m @ 1000 m | | Minimum Focus Distance | 3.9' / 1.2 m | | Exit Pupil Diameter | 4.2 mm | | Eye Relief | 15.0 mm | | Dioptric Correction | ±4 | | Focus Type | Center | | Tripod Mount | Yes (Adapter Optional) | | Dimensions | 5.5 x 5.0 x 2.0" / 14.0 x 12.7 x 5.1 cm | | Weight | 27.5 oz / 780.0 g |
