User Manual for Mirror Image VGA Mirror Adapter Box VGAMIRROR Click to enlarge the picture
Contents of the user manual for the Mirror Image VGA Mirror Adapter Box
- Product category: Teleprompter Accessories Mirror Image
- Brand: Mirror Image
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Mirror Image Teleprompter Accessories
|
User manual for the Mirror Image VGA Mirror Adapter Box contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Mirror Image product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Mirror Image user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Mirror Image product will considerably shorten its lifespan!
|
Product description The VGA Mirror Adapter Box VGAMIRROR from Mirror Image is a high-performance universal VGA/HDTV to VGA/HDTV scan rate converter that can also mirror or duplicate the VGA input signal on the X axis. The video process combines the functions of a video scaler, scan converter, and format transformer. With this device, the resolution of any PC or HDTV video signal can be scaled up or down to any other PC or HDTV.
This unit automatically detects input mode and timing parameters and can be controlled via a simple, front-panel, push-button menu system. Since VGA output can be mirrored horizontally, it makes this unit an ideal solution for teleprompting and rear-projection systems. It also features a large video memory for real-time frame rate capture and conversion. Moreover, the picture output can be fine tuned (position & phase) and format conversion between RGBHV and YPbPr is possible. This unit is packaged in a durable and portable metal EMI shielded enclosure. - Mirror VGA Output
- Duplicate the video signal from your VGA or HDTV output with this innovative adapter box.
- Push-Button Control
- Timing parameters and other functions can be controlled via a simple, push-button menu control system.
In the Box Mirror Image VGA Mirror Adapter Box VGAMIRROR Adapter Box Two-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Mirror Image VGA Mirror Adapter Box VGAMIRROR in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMirror Image VGA MIRROR Specs | Material | Metal | | Finish | Black | | Input | PC (VGA/SVGA/XGA/SXGA)
HDTV (480i 576i 480p 567p 720p 1080i) | | Output | PC (VGA/SVGA/XGA/SXGA)
HDTV (480p/576p/720p/1080i) | | Connector Type | HD 15 Female | | Power | 115VAC to 12VDC @ 800mA In-Plug Switching Adapter | | Dimensions | 1-3/16 x 3 x 5-1/2" (30 x 75 x 140mm) | | Weight | 10 oz. (280 grams) | | | | Package Weight | 2.2 lb | | Box Dimensions (LxWxH) | 11.1 x 7.2 x 2.9" |
Rating80% users recommend this product to others. And what about you?
This product has already been rated by 84 owners. Add your rating and experience with the product.
