Product description The mSAN 16 16-Bay Thunderbolt 3 Shared Storage Solution from mLogic is a storage area network (SAN) that can accommodate up to four directly-connected Windows or Mac systems via its four Thunderbolt 3 ports, which is expandable to 16 systems using its SAS expander port. The Thunderbolt 3 ports can also be used for daisy-chaining up to six Thunderbolt devices, including dual 4K displays or a single 5K display.
Powered by a 1.2 GHz RAID-on-Chip Dual-Core processor and 2GB of DDR3 RAM, the mSAN 16 has a 2 RU form factor and sixteen drive bays that support 3.5"/2.5" SAS-2 or SATA III 6 Gb/s hard drives and SSDs. Users will be able to configure this RAID with just hard drives, just SSDs, or mix and match the two for data transfer rates up to 2600 MB/s. Once installed, these sixteen drive bays can be configured in a variety of hardware-controlled RAID modes, including RAID 0, 1, 5, 6, and 10, each of which offers performance, data redundancy, or a combination of both. For those who do not require a RAID, JBOD is also available.
mLogic's mSAN 16 is cooled using dual fans and has dual internal power supplies. Included is a Thunderbolt 3 cable, sixteen removable drive bays with hardware, and a power cord, as well as full versions of Hedge and KYNO software, and mLogic's RAID Manager app. Protection is provided by a limited 3-year warranty.
Please be aware that this 4-seat shared storage solution requires SAN software, such as Tiger Store or Apple Xsan, and a Windows or Mac metadata controller (MDC) to enable sharing. General Features - Sharing
- The mSAN 12 is a shared storage system that enables up to four computers to directly attach via Thunderbolt 3, thus empowering collaborative workflows. The mSAN 12 can scale to support up to 16 host systems.
- Performance up to 2600 MB/s - Mix & Match HDDs and SSDs
- The mSAN 12 features twelve removable drive bays that support either 2.5"/3.5" SAS-2 or SATA III 6 Gb/s hard drives or SSDs. Simply add your own hard drives, SSDs, or a combination of both. When SSDs are installed, it is possible to achieve data transfer rates of up to 2600 MB/s.
- User-Friendly GUI, High-Speed Hardware RAID
- The mSAN 12 supports a variety of hardware-controlled RAID modes, including RAID 0, 1, 5, 6, 10, and JBOD. The dedicated 1.2 GHz Dual-Core RAID-on-Chip processor with 2GB of DDR3 RAM offloads RAID processing from the host system, helping to ensure stable and high-performance data transfers. Setting up a RAID set is user-friendly using the included mLogic RAID Manager.
- Built-In SAS Expansion, Daisy-Chain up to Six Thunderbolt Devices
- The mSAN 12 is equipped with a SAS expander port and 40 Gb/s Thunderbolt 3 ports that enable the daisy chaining of up to six Thunderbolt devices, including dual 4K displays or a single 5K display.
- Free Hedge and KYNO Software
- The mSAN 12 is bundled with full versions of Hedge and KYNO software. Hedge Backup Software for Filmmakers is an app for Windows and Mac that makes multiple backups of your footage, while KYNO is a smart all-in-one media management app for Windows & Mac that delivers ingest-free media management, screening, and transcoding that adjusts to your workflow.
UPC: 854927003893 In the Box mLogic mSAN 16 16-Bay Thunderbolt 3 Shared Storage Solution 16 x Drive Trays with Hardware Thunderbolt 3 Cable Power Cord mLogic RAID Manager App Hedge Software License KYNO Software License Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the mLogic mSAN 16 16-Bay Thunderbolt 3 Shared Storage Solution in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersmLogic mSAN 16 Specs | | | Number of Bays | 16 x 2.5"/3.5" | | Media Card Slots | None | | Connections | 4 x USB Type-C (Thunderbolt 3 (40 Gb/s)) | | RAID Modes | RAID 0, 1, 10, 5, 6, JBOD | | | | Total Raw Capacity | None | | Type | None | | Flash Memory | None | | | | Clock Speed | Base: 1.2GHz | | Total Installed Memory | 2 GB DDR3 | | | | OS Compatibility | Windows
macOS | | | | Dimensions | 22.3 x 17.6 x 5.2" / 566.4 x 447.0 x 130.8 mm | | Weight | 30.0 lb / 13.6 kg |
