Product description The black v26 6MP Network Camera with Night Sensor Module from MOBOTIX has a 1/1.8" progressive scan CMOS sensor to capture 3072 x 2048 resolution video at up to 12 fps. Recorded footage is stored on an internal 4GB microSD card. Integrated PoE technology simplifies connectivity by transferring data and power over one cable. Video management for this device is possible thanks to the MxManagementCenter VMS for Windows & Mac PCs, and the MOBOTIX app for iOS devices. This camera is IK10-rated for vandal resistance. - Night sensor module included
- Camera and data security includes user and group management, SSL connections, IP-based access control, IEEE 802.1x network access control, intrusion detection, and digital image signature
- USB interface to connect to external USB device
- -90 to 0° manually adjustable tilt angle of lens
- Programmable exposure zones
- Playback and QuadView via web browser
- Time controlled flexible event logic
- Event video and image transfer via FTP and email
- Weekly schedules for recordings and actions
- Master/slave communication
- Remote alarm notification
- MxMessageSystem for sending and receiving MxMessages
- Video analysis includes video motion sensor, MxActivitySensor, and MxAnalytics
- MxManagementCenter VMS for Windows & Mac PCs
- MOBOTIX mobile app compatible with iOS 6.0 and above
- 2 x I/O and RS-232 interfaces via optional accessories available separately
- Ceiling mountable with mounting hardware that is available separately
In the Box MOBOTIX v26 6MP Network Camera with Night Sensor Module (Black) Sealing 19.7" / 50cm Black Ethernet Patch Cable 2.5mm Allen Wrench TX20 Torx Wrench 4GB microSD Card (Installed) Red Lens Wrench 4 x Black Allen Screws M4 x 16mm 4 x
|
Upload User Manual
Have you got an user manual for the MOBOTIX v26 6MP Network Camera with Night Sensor Module in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMOBOTIX V26 Specs | | | Sensor | 6 MP 1/1.8" CMOS | | Minimum Illumination | B&W: 0.001 Lux | | | | Streaming Resolution | 3072 x 2048 at 4/12 fps
2592 x 1944 at 5/15 fps
2048 x 1536 at 9/20/24 fps
1920 x 1080 at 13/25/34 fps
1280 x 720 at 26/42 fps | | Supported Video Compression | H.264, MJPEG, MxPEG | | Multi-View Streaming | Yes | | | | Security | FTPS, HTTPS, IEEE 802.1X | | Supported Protocols | DHCP, FTP, HTTP, IPv4/v6, NTP, RTP, RTSP, SIPS, SMTP, SNMP v1/v2c/v3 (MIB-II), SSL/TLS, UDP | | | | Application Programming Interface (API) | ONVIF Profile S supported by future software update | | Analytics | Video motion sensor, MxActivitySensor, MxAnalytics | | Event Trigger | Yes | | Event Action | Recording, Notification, Alarm | | | | Mobile Operating Systems | iOS | | | | Memory | 1 GB RAM / 512 MB Flash | | Recording Media | microSD (Up to 4 GB) | | Pan/Tilt | None | | I/O Connections | 1 x RJ45 | | Video Management Software | MxManagementCenter, Mobile MOBOTIX App | | Internal Storage | None | | External Storage Options | NAS | | Power Source | PoE 802.3af (15 W) | | Power Consumption | PoE: 5 W | | Material of Construction | Polymer | | Operating Temperature | 32 to 104°F / 0 to 40°C | | IP Rating | IP20 | | IK Rating | IK10 | | Dimensions |
