Product description The 24Ao from MOTU is a single rack space USB 2.0 interface with industry-standard AVB networking for sub-millisecond network latency, and offers twenty-four channels of analog audio output combined with three banks of ADAT optical, for a total of seventy-two channels of I/O. The unit connects to a computer through USB 2.0, which provides more than enough bandwidth for the twenty-four analog channels, and when connected through AVB networking, supports hundreds of network channels.
All devices on an AVB network can stream audio to and from a computer, and everything can be controlled simultaneously from any computers, tablets, and smart phones connected to the network. The interface delivers excellent analog performance with digitally controlled analog trim on the analog inputs, and includes a forty-eight-channel software mixer modeled after large format mixing consoles, DSP effects with 32-bit floating point precision, flexible matrix-style routing and splitting, stand-alone operation, and Wi-Fi control. Note: Windows support to be added later. -
- Employs the same analog design as MOTU's 1248, 8M and 16A audio interfaces
- Seventy-two simultaneous audio channels: Twenty-four balanced analog outputs on three banks of multichannel connectors (D-sub and Phoenix), plus three banks of eight-channel ADAT optical
- Connects to a computer with audio class compliant high-speed USB 2.0 (compatible with USB 3.0 and iOS)
- Discovery app and web app software works alongside any host audio software
- On-board DSP with mixing and effects
- Flexible forty-eight input digital mixer modeled after large format mixing consoles, with twelve stereo busses and DSP effects, including reverb, four-band EQ, gate and compression
- DSP-driven mixing and effects engine delivers virtually unlimited headroom utilizing 32-bit floating point processing
- Modeled vintage effects processing with compression modeled after the legendary LA-2A compressor and EQ modeled after British analog console EQs
- Add a second MOTU AVB interface (24Ai, 24Ao, 1248, 8M or 16A) with a simple Cat-5e Ethernet cable
- Connect up to five MOTU interfaces using a MOTU AVB Switch (sold separately)
- Build an AVB network with multiple interfaces and computers using standard AVB switches and network cabling, with ultra-low network latency, even over long cable runs (100 meters point to point)
- Stream hundreds of audio channels among devices and computers on the network
- Matrix routing and splitting allows for sending any input to any output, or multiple outputs, including routing to and from the computer, plus any devices on the AVB network
- Control on-board DSP, mixing, device settings and network audio routing from web app software running in a preferred browser on a laptop, tablet or smart phone connected by wire or Wi-Fi to a local area network
- Standalone mixing with wireless control - connect an Apple Airport or other Wi-Fi router directly to the 24Ao with a standard Ethernet cable and control mixing and DSP effects from a smart phone or tablet, without a computer, great for live sound mixing
- Use the 24Ao as a twenty-four channel optical expander for other gear (24 channels at 44.1/48 kHz or 12 channels at 88.2/96 kHz)
- Large backlit 324 x 24 LCD allow for viewing all signal activity at a glance with detailed metering for all analog and digital I/O
- Access hardware settings from a simple and convenient menu
- Includes AudioDesk workstation software with 24-bit recording, sample-accurate editing and 32-bit mixing and mastering
UPC: 839128005952 In the Box MOTU 24Ao - USB/AVB 72 Channel Audio Interface AC Power Cable USB Cable Rack Ears AudioDesk DAW License Two (2) Year Limited Warranty User Manual PDF 5.5mbrfsxbedavvddzsadeeesvxzrwy Table of Contents
|
Upload User Manual
Have you got an user manual for the MOTU 24Ao - USB AVB 72 Channel Audio Interface in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMOTU 9335 Specs | | | Max Sample Rate/Resolution | 192 kHz / 24-Bit | | Display and Indicators | 1 x Graphic LCD (Menu Navigation, Metering) | | | | Host Connection | USB Type-B (USB 2.0) | | Analog I/O | 3 x DB25 8-Channel Output
6 x Phoenix 12-Pin Input | | Digital I/O | 3 x TOSLINK / ADAT, S/MUX, S/PDIF Input
3 x TOSLINK / ADAT, S/MUX, S/PDIF Output
1 x BNC (Word Clock) Input
1 x BNC (Word Clock) Output | | MIDI I/O | None | | | | Gain Range | Inputs:
-24 to 0 dB | | Max Input Level | Inputs:
+20 dBu | | Dynamic Range | 123 dBA | | THD+N | -110 dB | | | | Sample Rates | 44.1, 48, 88.2, 96, 176.4, and 192 kHz | | Bit Depth | 24-Bit | | | | OS Compatibility | macOS 10.8 or Later
Windows 8 or Later | | Processor Requirement | Mac:
1 GHz Intel
PC:
1 GHz Intel Pentium | | RAM Requirements | 2 GB (4 GB Recommended) | | Storage Requirements | 500 GB | | Required Hardware | Available USB 2.0 Port | | | | AC Input Power | 100 to 240 VAC at 50/60 Hz | | | | Dimensions | 17 x 7 x 2" / 432 x 178 x 51 mm Without Included Rack Ears | | Weight | 7.0 lb / 3.2 kg | | | | Package Weight | 6.25 lb | | Box Dimensions (LxWxH) | 23.543 x 11.496 x 5.433" |
