Product description The HD192 hard disc recording system from MOTU provides an interface with twelve, high-quality, 24-bit/192kHz analog inputs and outputs. The interface is designed with the latest generation 24-bit, enhanced multi-bit, 128x oversampling 192kHz converters, which deliver a remarkable A-weighted signal-to-noise ratio of 120dB. In addition to the interface the system includes a PCI-424 card and Audiodesk workstation software. Audio activity for every input and output is represented on the front panel by dedicated nineteen-segment LED bar graph. The twelve analog inputs and outputs are on XLR connectors operating at +4dB. AES/EBU digital input and output is also provided with the added ability of delivering sample rate conversion both on input and output. Two "over" meters are included - a temporary over meter and an over/hold meter that is re-settable via software. Comprehensive clock status LEDs are also included that show at a glance the current sampling rate and clock source. Wordclock sync is provided on BNC connectors. The HD192 uses the second generation AudioWire protocol, a high-bandwidth digital audio format capable of carrying up to twenty-four channels of 96kHz or twelve channels of 192kHz digital audio in and out of the computer at the same time. The included PCI-424 card features a powerful DSP chip dedicated to creating a custom tailored monitor mix of up to ninety-six channels of audio. Because the mixing takes place on the card itself, the system provides near-zero latency performance. Up to four audio interfaces (which are hot swappable) can be connected to a PCI-424 in any combination. - Expandable hard disc recording system
- Up to four HD192 units can be connected to a PCI-424 audio card for a total of 48 inputs and outputs
- User can have as many simultaneous channels as the host software and computer allow
- Compatible with all MOTU AudioWire interfaces
- Includes ASIO drivers for Mac OS and Windows
- Multi-channel WDM driver provides simultaneous inputs/outputs for all Windows audio applications that support standard WDM and multi-channel Wave drivers
- Fully compatible with VST, MAS, Premiere, DirectX, and all other host-based native plug-in formats
In the Box MOTU HD192 (PCI 424) - 12 Input / 12 Output High Resolution Hard Disc Recording System with PCI 424 Card for Mac and PC PCI 424 Host Card HD192 Audio Interface AC Power Cable AudioWire Cable AudioDesk Software Limited 2-Year Warranty Guides & Manuals yuuytzzcyrxdzbraw Table of Contents
|
Upload User Manual
Have you got an user manual for the MOTU HD192 - 12 Input 12 Output High Resolution Hard Disc Recording System with PCI 424 Card for Mac and PC in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Download User ManualThe user manual for the MOTU HD192 - 12 Input 12 Output High Resolution Hard Disc Recording System with PCI 424 Card for Mac and PC can be downloaded in PDF format at the link stated below.
Technical parametersMOTU HD192 Specs | Converters | 24-bit | | Sample Rates | 44.1, 48, 88.2 and 96kHz | | Analog In | 12 x XLR, balanced | | Analog Outputs | 12 x XLR, balanced | | Digital Input Connectors | 1 x XLR, AES/EBU (stereo) | | Digital Output Connectors | 1 x XLR, AES/EBU (stereo) | | MIDI In/Out | No | | Sync In/Out | Word clock, AES sync | | Headphone Output | No | | THD + N | 0.00056% (-106dB) | | Dynamic Range | 120dB, A-weighted | | Frequency Response | Not specified by manufacturer | | Minimum System Requirements | Mac:
