User Manual for Moultrie A40 Pro Game Camera Click to enlarge the picture
Contents of the user manual for the Moultrie A40 Pro Game Camera
- Product category: Trail/Wildlife Cameras Moultrie
- Brand: Moultrie
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Moultrie Trail/Wildlife Cameras
 |
User manual for the Moultrie A40 Pro Game Camera contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Moultrie product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Moultrie user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Moultrie product will considerably shorten its lifespan!
|
Product description Capture 14MP photos and 720p video of game (or human) activity on your property or hunting grounds with the Moultrie A40 Pro Game Camera. Moultrie's Illumi-Night 2 sensor captures a clear, bright picture, and the 0.7-second trigger speed, 70' motion detection range and low-glow 70' flash range will make sure you get the images and footage you need. Backlit controls make it easy to operate the camera in low light, and the interface is intuitive to use. The A40 records photos and videos to a user-supplied SD/SDHC class 4 or higher memory card, up to 32GB. Power is provided by 8 user-supplied AA batteries or via an optional external power supply. The camera is compatible with Moultrie Mobile cellular service when paired with a separately sold Moultrie MV1 Field Modem. - Photo/Video Performance
-
- Maximum still image resolution: 14MP
- 720p video with sound
- Motion Detection
-
- Detection range: 70'
- Trigger speed: 0.7 sec
- Memory
-
- Records images and video to user-supplied SD/SDHC Class 4 or higher memory cards up to 32GB
- Power
-
- Runs on 8 user-supplied AA batteries, which allow you to capture about 17,000 images depending on usage and settings
- Compatible with any Moultrie 12 VDC external power source
- Can also run on optional AC power supply
- Connectivity
-
- Compatible with Moultrie Mobile Wireless Modem MV1, which grants you remote access to camera via Verizon Wireless network
- Mounting
-
- Standard 1/4"-20 threaded hole on bottom for connection to optional tree/post mounts
- Slots in back for nylon strap or optional Python lock cable
- Durability
-
- Rugged, weatherproof plastic housing protects camera from the elements over extended periods of outdoor use
UPC: 053695132730 In the Box Moultrie A40 Pro Game Camera Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Moultrie A40 Pro Game Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMoultrie A40 Specs | Camera Type | Surveillance/Time Lapse/Trail/Wildlife | | | | Image Resolution | 14 MP | | Built-In Flash | 24 x Black Low-Glow 850 nm Wavelength IR LEDs | | Effective Flash Range | 70' / 21.3 m | | Time/Date Stamp | Yes | | | | Sensor Type | Passive Infrared (PIR) | | Detection Range | 70' / 21.3 m | | Trigger Speed | 0.7 Seconds | | | | Audio Recording | Yes | | Video Format | 1280 x 720p | | | | Memory Card Type | SDHC (Up to 32 GB) | | Battery Type | 8 x AA (Not Included) | | External Power Source Capable | Yes, 12 VDC (Not Included) | | Security | Holed for Locking | | Mounting | 1/4"-20 Female
Mounting Strap (Not Included) | | | | Package Weight | 0.99 lb | | Box Dimensions (LxWxH) | 9.2 x 5.45 x 2.85" |
