User Manual for Moultrie M50 Trail Camera Click to enlarge the picture
Contents of the user manual for the Moultrie M50 Trail Camera
- Product category: Trail/Wildlife Cameras Moultrie
- Brand: Moultrie
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Moultrie Trail/Wildlife Cameras
 |
User manual for the Moultrie M50 Trail Camera contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Moultrie product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Moultrie user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Moultrie product will considerably shorten its lifespan!
|
Product description Capture 20MP photos and full HD 1080p video of game (or human) activity on your property or hunting grounds with the Moultrie M50 Trail Camera. Moultrie's Illumi-Night 2 sensor captures a clear, bright picture, and the fast 0.3-second trigger speed, 80' motion detection range and low-glow 100' flash range will make sure you get the images and footage you need. Backlit controls make it easy to operate the camera in low light, and the interface is password protected. In addition to motion-detection mode, the camera can also operate in time-lapse mode, taking photos at programmable intervals, or in both modes at once. The M50 records photos and videos to a user-supplied SD/SDHC class 4 or higher memory card, up to 32GB. (You have the option of overwriting the oldest images once the card fills up.) Power is provided by 8 user-supplied AA batteries or via an optional external power supply. The camera is compatible with Moultrie Mobile cellular service when paired with a separately sold Moultrie MV1 Field Modem. - Photo/Video Performance
-
- Maximum still image resolution: 20MP
- Full HD 1920 x 1080p video with sound
- Multi-shot burst capability: 1, 3 burst, 3 triggered
- Time, date, moon phase, and temperature stamp on images
- Motion Detection
-
- Detection range: 80'
- Trigger speed: 0.3 sec
- Time Lapse
-
- Automatically takes pictures at programmable intervals over a given period of time
- Selectable intervals: 10, 30 seconds / 1, 5, 10, 15, or 30 minutes / 1, 2, 3, 6, 12 hours / 1 day
- Time lapse and motion detection modes can be used simultaneously
- Memory
-
- Records images & video to user-supplied SD/SDHC Class 4 or higher memory cards up to 32GB
- Power
-
- Runs on 8 user-supplied AA batteries, which allow you to capture about 19,000 images depending on usage and settings
- Compatible with any Moultrie 12 VDC external power source
- Can also run on optional AC power supply
- Connectivity
-
- Compatible with Moultrie Mobile Wireless Modem MV1, which grants you remote access to camera via Verizon Wireless network
- Mounting
-
- Standard 1/4"-20 threaded hole on bottom for connection to optional tree/post mounts
- Slots in back for nylon strap or optional Python lock cable
- Durability
-
- Rugged, weatherproof plastic housing protects camera from the elements over extended periods of outdoor use
UPC: 053695132716 In the Box Moultrie M50 Trail Camera (Moultrie Bark Camo) Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Moultrie M50 Trail Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMoultrie M50 Specs | Camera Type | Surveillance/Time Lapse/Trail/Wildlife | | | | Image Resolution | 20 MP | | Additional Resolutions | 8 MP x
4 MP x
2 MP x | | Built-In Flash | 32 x Black Low-Glow 850 nm Wavelength IR LEDs | | Effective Flash Range | 100' / 30.5 m | | Time/Date Stamp | Yes | | | | Sensor Type | Passive Infrared (PIR) | | Detection Range | 80' / 24.4 m | | Trigger Speed | 0.3 Seconds | | | | Audio Recording | Yes | | Video Format | 1920 x 1080
1280 x 720 | | Video Clip Length | 5, 10, 30, 60, 90 Seconds
30 Seconds (Nighttime Max) | | | | Memory Card Type | SDHC (Up to 32 GB) | | Battery Type | 8 x AA (Not Included) | | External Power Source Capable | Yes, 12 VDC (Not Included) | | Security | Holed for Locking | | Mounting | 1/4"-20 Female
Mounting Strap (Not Included) | | | | Package Weight | 1.14 lb | | Box Dimensions (LxWxH) | 9.4 x 5.45 x 3.3" |
Rating60% users recommend this product to others. And what about you?
This product has already been rated by 85 owners. Add your rating and experience with the product.
