Product description CES 2017: MSI Launches New B250, H270, and Z270 Motherboards Read More The MSI B250 PC Mate LGA1151 ATX Motherboard lets you build a Windows system that sports a 6th- or 7th-generation Intel processor and up to two dedicated graphics cards. The B250 PC Mate features an Intel B250 chipset and an LGA1151 socket to become compatible with Intel's Core i3, Core i5, Core i7, Pentium, and Celeron processors. It comes with four DIMM slots, which can accommodate up to 64GB of DDR4 memory chips, as well as six SATA interfaces for your 2.5" and 3.5" storage drives. For faster access to your data, the B250 PC Mate supports up to two ultra-fast SSDs with an M.2 form factor, offering you the ability to RAID these type of drives.
The B250 PC Mate motherboard comes with a total of eight USB ports with varying speeds. For connections with keyboards and mice, two USB 2.0 ports are available. To connect with printers, scanners, and external storage drives, this motherboard offers four USB 3.0 ports, which deliver speeds of up to 5 Gb/s. With speeds of 10 Gb/s, the two onboard USB 3.1 ports are suitable for transferring large-sized files from digital cameras. Moreover, one of these two USB 3.1 ports features a reversible USB Type-C design, letting you connect your USB-C cable the first try.
MSI has outfitted this motherboard with HDMI, DVI-D, and VGA outputs to deliver detailed visuals to your monitors utilizing integrated Intel graphics. With two PCIe 3.0 x16 slots available, you can install optional graphics cards to edit videos and create 3D environments. Furthermore, three PCIe 3.0 x1 slots and one PCI slot are on board, letting you expand the motherboard's capabilities.
Aside from slots, the B250 PC Mate motherboard is equipped with an Intel Gigabit Ethernet port along with a Realtek ALC887 audio codec chipset, which immerses you in 7.1-channel sounds through your speakers or headset. - Intel B250 Chipset
- The B250 chipset is designed to support Intel's 6th and 7th-generation of processors.
- Intel LGA1151 Socket
- This motherboard supports Intel Core i7/i5/i3/Pentium/Celeron processors in the LGA1151 package. These processors come with integrated graphics, memory, and PCI-Express controllers to deliver onboard graphics, dual-channel DDR4 memory support, and PCI Express 3.0 lanes for graphics performance.
Additional Features - DDR4 Boost gives your DDR4 memory modules a performance boost
- Audio Boost rewards your ears with studio grade sound quality for a Hi-Fi experience
- EZ Debug LED provides an easy way to troubleshoot problems
- Twin Turbo M.2 delivers speeds of up to 32 Gb/s
- Intel Optane memory ready
- M.2 Genie makes setting up a RAID for M.2 SSDs easier and faster
- USB 3.1 Type-C and USB 3.1 Type-A ports offer speeds of up to 10 Gb/s
- Increase your USB and storage performance with the X-Boost tool
- Double ESD Protection features double-layer grounding mounting holes
UPC: 824142138311 In the Box MSI B250 PC Mate LGA1151 ATX Motherboard Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the MSI B250 PC Mate LGA1151 ATX Motherboard in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMSI B250 Specs | CPU Support | Supports 6th/7th-Gen Intel Core i3/i5/i7 processors along with Intel Pentium and Celeron processors for Socket LGA1151 | | Chipset | Intel B250 | | RAM | 4 x DDR4 memory slots support up to 64 GB
Supports DDR4 2400/2133 MHz (7th-generation Intel CPU) or 2133 MHz (6th-generation Intel CPU)
Dual-channel memory architecture | | Slots | 2 x PCIe 3.0 x16
3 x PCIe 3.0 x1
1 x PCI
2-Way AMD Crossfire Support | | Audio | Realtek ALC887 Codec | | Internal I/O Connectors | 6 x SATA 6 Gb/s connectors
2 x M.2 slots
1 x USB 3.0 connector (supports additional 2 USB 3.0 ports)
2 x USB 2.0 connectors (support additional 4 USB 2.0 ports) | | Supported RAID Levels | RAID 0, 1, 5, 10 for SATA drives | | Back Panel I/O Ports | 1 x HDMI
1 x DVI-D
1 x VGA
1 x PS/2 combo
1 x USB 3.1 Type-A
1 x USB 3.1 Type-C
4 x USB 3.0 Type-A
2 x USB 2.0 Type-A
3 x Audio
1 x Intel I219-V Gigabit Ethernet | | Form Factor | ATX | | Dimensions | Not Specified by Manufacturer | | Weight | Not Specified by Manufacturer | | | | Package Weight | 2.85 lb | | Box Dimensions (LxWxH) | 13.6 x 10.6 x 2.7" |
