Product description The B350 PC Mate AM4 ATX Motherboard from MSI lets you build a Windows system that supports an AMD RYZEN, A-series, or Athlon processor by featuring an AMD B350 chipset along with an AM4 socket. The motherboard can accommodate up to 64GB of DDR4 memory chips as well as four SATA-based drives, such as DVD burners, HDDs, and SSDs. For ultra-fast SSD support, it comes armed with an M.2 slot that can accept PCIe- or SATA-based SSDs with a length of 42, 60, 80, or 110mm.
The B350 PC Mate can deliver up to 4096 x 2160 resolutions utilizing an integrated APU processor or render detailed textures smoothly by installing an optional graphics card in its single PCIe 3.0 x16 slot. Visuals from an APU chipset are delivered through the motherboard's VGA, DVI-D, and HDMI outputs. Additionally, one PCIe 2.0 x16 slot along with two PCIe 2.0 x1 and two PCI slots are available to provide additional capabilities to your system.
MSI has equipped this motherboard with a Realtek 8111H LAN controller that connects to networks at Gigabit speeds. For accessing printers, scanners, and other gear, the motherboard has two USB 2.0 and four USB 3.0 ports. Moreover, one of these four USB 3.0 ports features a USB Type-C interface that allows you to connect on the first try with a user-supplied USB-C cable. Other notable connections include six audio jacks powered by a Realtek ALC892 audio processor. - AM4 Socket
- AM4 chipsets provide dedicated PCIe lanes for USB, graphics, data, and other I/O.
- Cooling
- MSI fan headers automatically detect fans running in DC or PWM mode for optimal tuning of fan speeds and silence. Hysteresis technology is on board to make your fans spin up fluently to help ensure your system stays silent. Total Fan Control software is offered so you can take control of your fans and check the system's characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for the CPU and motherboard, which will adjust the fan's speeds automatically. Additionally, the motherboard comes with a water-pump PIN header that supports up to 2A, offering you full control of the water pump's speed.
- Audio
- This motherboard offers studio grade sound by offering separated audio layers, golden audio jacks, and Chemi-Con audio capacitors as well as an isolated audio design, De-Pop protection, and EMI-shielded HD audio processor.
- Software Included
-
- X-Boost increases USB speeds of up to 20% and optimizes SSDs to keep the system fast and maximize storage
- Network Genie for cloud computing and data syncing as well as changing the application's traffic priority
- DDR4 Boost enhances memory speeds
- MSI Command Center allows you to tune settings to increase system stability, maximize performance, and optimize cooling
- RAMDisk creates a virtual drive from RAM
- MSI M-Cloud can turn your system into an access point and personal cloud
- CLICK BIOS 5 offers sharp scalable fonts and EZ and Advanced modes as well as search and favorites features to help you configure the system's components
- Secure Erase+ uses an optimized formatting algorithm, so SSDs can operate at maximum speeds
- MSI OC Genie helps you overclock a processor with a single button
- Additional Features
-
- DVI and VGA video outputs for legacy monitors, beamers, and other displays
- 2-Way AMD CrossFire technology support
- M.2 slots deliver speeds of up to 32 Gb/s using PCIe 3.0 x4 lanes
- LAN Protect shields the motherboard from power surges
- Fully isolated memory circuitry and optimized traces help ensure stability and performance
- Onboard LEDs for key components indicate the source of the problem, so you'll know what to fix
- Overvoltage protection prevents potential short-circuit damage to the CPU and other critical components
- USB Type-C interface offers effortless connections to USB-C cables
- Protective ICs prevent damage caused by Electrostatic Discharge (ESD) from plugging/unplugging USB devices
- MSI Super Charger USB ports deliver more power than standard ports to charge mobile devices quickly
- PCI Express Steel Armor slots are armed with more solder points to prevent electromagnetic interference and damage from heavy graphics cards
- Double ESD protection and double layer grounding around the motherboard mounting holes to protect the motherboard from Electrostatic discharge (ESD) surges
UPC: 824142143698 In the Box MSI B350 PC Mate AM4 ATX Motherboard Drivers & Utilities Disc I/O Shield 2 x SATA Cable Limited 3-Year Warranty User Manual PDF 5.9mbawqztxttdybqvasfwauucsrauz Table of Contents
|
Upload User Manual
Have you got an user manual for the MSI B350 PC Mate AM4 ATX Motherboard in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMSI B350 PC MATE Specs | | | Chipset | AMD B350 | | CPU Socket | AM4 | | | | USB | 2 x USB 2.0 Type-A
3 x USB 3.1 Gen 1 Type-A
1 x USB 3.1 Gen 1 Type-C | | Display | 1 x VGA
1 x DVI-D
1 x HDMI | | Audio | 6 x 3.5 mm | | Ethernet / Controller | 1 x Realtek 8111H Gigabit | | PS/2 | 1 x Combo | | | | Memory Slots | 4 x 288-Pin | | Memory Support | DDR4 1866, 2133, 2400, 2667, 2933, 3200 MHz | | Maximum Capacity | 64 GB | | Channel Architecture | Dual Channel | | | | SATA | 4 x SATA III | | M.2 | 1 x M Key 2242, 2260, 2280, 22110 (PCIe 3.0 x4, SATA III) | | U.2 | None | | RAID Support | RAID 0, 1, 10 (SATA) | | | | Expansion Slots | 1 x PCIe 3.0 x16
1 x PCIe 2.0 x16
2 x PCIe 2.0 x1
2 x PCI | | USB | 2 x USB 3.1 Gen 1 Header (Supports 4 USB Type-A Ports)
2 x USB 2.0 Header (Supports 4 USB Type-A Ports) | | Multi-GPU Support | 2-Way AMD CrossFireX | | Air Cooling | 1 x 4-Pin CPU
4 x 4-Pin System | | Liquid Cooling | 1 x 4-Pin Pump | | Power Connectors | 1 x 24-Pin Mainboard
1 x 8-Pin CPU | | Security | Chassis Intrusion, TPM Module | | LED Header | 1 x RGB | | Diagnostics | Clear CMOS | | Legacy | 1 x Parallel
1 x Serial | | | | I/O Connection Headers | AAFP | | | | Audio Codec | Realtek ALC892 (8-Channel) | | | | Supported Operating Systems | Windows 10 (64-Bit)
Windows 7 (64-Bit) | | | | Form Factor | ATX | | Dimensions | 12.0 x 9.6" / 30.5 x 24.4 cm | | | | Package Weight | 2.95 lb | | Box Dimensions (LxWxH) | 13.7 x 10.6 x 2.6" |
