User Manual for MSI B360M Gaming Plus LGA 1151 Micro-ATX Motherboard Click to enlarge the picture
Contents of the user manual for the MSI B360M Gaming Plus LGA 1151
- Product category: Motherboards MSI
- Brand: MSI
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for MSI Motherboards
 |
User manual for the MSI B360M Gaming Plus LGA 1151 contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any MSI product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official MSI user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a MSI product will considerably shorten its lifespan!
|
Product description The B360M Gaming Plus LGA 1151 Micro-ATX Motherboard from MSI is built on the Intel B360 chipset and has a LGA 1151 socket designed for 8th generation Intel Core, Pentium Gold, and Celeron processors. It's equipped with two DDR4 memory slots that support up to 32GB of 2666 MHz RAM. For storage, it has six SATA III ports and a single M.2 slot, which also supports Intel Optane Memory. For gaming, the B360M Gaming Plus has a single PCIe 3.0 x 16 slot for your graphics card and two PCIe 3.0 x 1 slots for other PCIe-based hardware. Other integrated features include Intel Gigabit LAN, VGA, DVI-D, and HDMI outputs, and Realtek ALC887 7.1-channel high-definition audio. Moreover, this motherboard is equipped with RGB lighting that you can customize using MSI's downloadable software. - MSI Mystic Light
- This motherboard is equipped with MSI Mystic Light, which features millions of colors to choose from, a variety of lighting effects, and the ability to sync it with your other RGB-compatible products.
- Cooling
- The B360M Gaming Plus features three fan headers that support DC and PWM modes for complete fan control.
- DDR4 RAM
- The memory circuity on this motherboard has an optimized layout for stability. Moreover, it supports a wide variety of RAM from multiple manufacturers as well as Intel's Extreme Memory Profile (XMP) for enhanced performance.
- M.2 Slot
- The M.2 slot on this motherboard supports transfer speeds of up to 32 Gb/s using the PCIe Gen3 x4 interface. It also supports Intel Optane Memory to speed up system performance. Using MSI's software, you can enable X-Boost, which optimizes your SSD to maximize its storage performance.
- Gaming Audio
-
- Audio Boost - Delivers an enhanced and immersive listening experience with multiple hardware and software features.
- Nahimic 3 - Provides you with virtual 7.1-channel surround sound, control over your audio, and even an in-game overlay that informs you of which direction sounds are coming from.
- Isolated Audio Design with LED Border - Physically isolated circuitry ensures better audio signal.
- Separated Audio Layers - Separated layers in the PCB provide better sound quality for left- and right-audio channels.
- De-Pop Protection - Eliminates loud popping sounds when plugging or unplugging devices, or turning your system on or off.
- Dedicated Audio Processor - An EMI-shielded HD audio processor offers enhanced sound quality for both stereo and surround sound.
- Quality Capacitors - Golden audio capacitors ensure reliable and clear sound output.
- Golden Connectors - Gold prevents corrosion or oxidation, which can impact signal quality.
- Gaming Features
-
- Voice Boost - Automatically reduces the game's audio when teammates speak and readjusts it back when no one is talking.
- Gaming Hotkey - Assign functions to any key to launch games, load profiles, overclock in real-time, and much more.
- Dedicated Gaming Port - The dedicated Gaming Device Port is built with additional materials for better signal and durability. You can also customize your mouse options using the Mouse Master software.
- Steel Armor - Steel-reinforced PCIe slot enhances slot durability, prevents EMI and damage from GPU sag.
UPC: 824142160237 In the Box MSI B360M Gaming Plus LGA 1151 Micro-ATX Motherboard Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the MSI B360M Gaming Plus LGA 1151 Micro-ATX Motherboard in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMSI B360M Gaming Plus Specs | | | Chipset | Intel B360 | | CPU Socket | LGA 1151 | | | | USB | 2 x USB 2.0 Type-A
3 x USB 3.1 Gen 1 Type-A
1 x USB 3.1 Gen 1 Type-C | | Display | 1 x VGA
1 x DVI-D
1 x HDMI 1.4 | | Audio | 3 x 3.5 mm | | Ethernet / Controller | 1 x Intel I219-V Gigabit | | PS/2 | 1 x Combo | | | | Memory Slots | 2 x 288-Pin | | Memory Support | DDR4 2133, 2400, 2666 MHz | | Maximum Capacity | 32 GB | | Channel Architecture | Dual Channel | | ECC Support | Non-ECC Unbuffered | | | | SATA | 6 x SATA III | | M.2 | 1 x M Key 2242, 2260, 2280, 22110 (PCIe 3.0 x4, SATA III) | | U.2 | None | | | | Expansion Slots | 1 x PCIe 3.0 x16
2 x PCIe 3.0 x1 | | USB | 1 x USB 3.1 Gen 1 Header (Supports 2 USB Type-A Ports)
2 x USB 2.0 Header (Supports 4 USB Type-A Ports) | | Multi-GPU Support | None | | Air Cooling | 1 x 4-Pin CPU
2 x 4-Pin System | | Power Connectors | 1 x 24-Pin Mainboard
1 x 8-Pin CPU | | Security | Chassis Intrusion, TPM Module | | LED Header | 1 x RGB | | Audio | None | | Diagnostics | Clear CMOS | | Legacy | 1 x Parallel
1 x Serial | | | | I/O Connection Headers | USB 3.1 | | | | Audio Codec | Realtek ALC887 (7.1-Channel) | | | | Supported Operating Systems | Windows 10 (64-Bit) | | | | Form Factor | Micro-ATX | | Dimensions | 9.6 x 8.1" / 243.84 x 205.74 mm | | | | Package Weight | 1.9 lb | | Box Dimensions (LxWxH) | 11.0 x 11.0 x 3.0" |
