Product description CES 2017: MSI Launches New B250, H270, and Z270 Motherboards Read More The MSI Z270M Mortar LGA1151 mATX Motherboard lets you build a Windows system that sports a 6th- or 7th-generation Intel processor and up to two dedicated graphics cards. The Z270M Mortar features an Intel Z270 chipset and an LGA1151 socket to become compatible with Intel's Core i3, Core i5, Core i7, Pentium, and Celeron processors. Regardless of a micro-ATX form factor, it still comes with two PCIe 3.0 x16, two PCIe 3.0 x1, and four DIMM slots. For storage, it offers six SATA interfaces for your 2.5" and 3.5" storage drives as well as an M.2 slot for an ultra-fast SSD.
MSI has outfitted this motherboard with HDMI, DVI-D, and DisplayPort outputs to deliver detailed visuals to your monitors utilizing integrated Intel graphics. With two PCIe 3.0 x16 slots available, you can install optional graphics cards and link them with AMD CrossFire technology to enable high-performance gaming.
Aside from the slots, the Z270M Mortar motherboard is equipped with an Intel Gigabit Ethernet port along with a Realtek ALC1220 audio processor, which immerses you in 7.1-channel sounds through your speakers or headset. Other notable features include four USB 3.0 and two USB 2.0 ports, letting the system access printers, scanners, and external storage drives. Moreover, one of the four USB 3.0 ports features a USB Type-C interface, which lets you connect a USB-C cable the first try. - Intel Z270 Chipset
- The Z270 chipset is designed to support Intel's 6th and 7th-generation of processors.
- Intel LGA1151 Socket
- This motherboard supports Intel Core i7/i5/i3/Pentium/Celeron processors in the LGA1151 package. These processors come with integrated graphics, memory, and PCI-Express controllers to deliver onboard graphics, dual-channel DDR4 memory support, and PCI Express 3.0 lanes for graphics performance.
Additional Features - DDR4 Boost gives your DDR4 memory modules a performance boost
- Turbo M.2, Steel Armor, and Intel Optane memory ready for a fast game experience
- Audio Boost rewards your ears with studio grade sound quality for a Hi-Fi experience
- Gaming LAN with LAN Protect provides low latency and bandwidth management
- Military Class 5 and Guard Pro for enhanced protection and efficiency
- One PCIe 3.0 x16 slot covered with Steel Armor
UPC: 824142140178 In the Box MSI Z270M Mortar LGA1151 mATX Motherboard Limited 2-Year Warranty User Manual PDF 7.3mbxzwafayczvfbsfswxsfafxraxqfr Table of Contents
|
Upload User Manual
Have you got an user manual for the MSI Z270M Mortar LGA1151 mATX Motherboard in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMSI Z270M Specs | | | Chipset | Intel Z270 | | CPU Socket | LGA 1151 | | | | USB | 1 x USB 3.1 Gen 1 Type-C
3 x USB 3.1 Gen 1 Type-A
2 x USB 2.0 Type-A | | Display | 1 x HDMI
1 x DVI-D
1 x DisplayPort | | Audio | 6 x 3.5 mm | | Ethernet / Controller | 1 x Intel I219V Gigabit | | PS/2 | 1 x Combo | | | | Memory Slots | 4 x 288-Pin | | Memory Support | DDR4 2133, 2400, 2600, 2800, 3000, 3200, 3600, 3800 MHz | | Maximum Capacity | 64 GB | | Channel Architecture | Dual Channel | | | | SATA | 6 x SATA III | | M.2 | 1 | | U.2 | None | | RAID Support | RAID 0, 1, 5, 10 | | | | Expansion Slots | 2 x PCIe 3.0 x16
2 x PCIe 3.0 x1 | | USB | 2 x USB 3.1 Gen 1 Header (Supports 4 USB Type-A Ports)
2 x USB 2.0 Header (Supports 4 USB Type-A Ports) | | Multi-GPU Support | 2-Way AMD CrossFireX | | Air Cooling | None | | | | I/O Connection Headers | AAFP | | | | Audio Codec | Realtek ALC1220 (8-Channel) | | | | Package Weight | 2.7 lb | | Box Dimensions (LxWxH) | 11.1 x 10.8 x 3.3" |
