MSI Z390-A PRO LGA 1151 ATX

Search your instruction manual in PDF to download

User Manual for MSI Z390-A PRO LGA 1151 ATX Motherboard

Click to enlarge the picture
MSI Z390-A PRO LGA 1151 ATX Motherboard Contents of the user manual for the MSI Z390-A PRO LGA 1151 ATX
  • Product category: Motherboards MSI
  • Brand: MSI
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for MSI Motherboards

MSI Z390-A PRO LGA 1151 ATX Motherboard MSI Z390-A PRO LGA 1151 ATX Motherboard MSI Z390-A PRO LGA 1151 ATX Motherboard MSI Z390-A PRO LGA 1151 ATX Motherboard MSI Z390-A PRO LGA 1151 ATX Motherboard
User manual for the MSI Z390-A PRO LGA 1151 ATX contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any MSI product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official MSI user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a MSI product will considerably shorten its lifespan!



Product description

The Z390-A PRO LGA 1151 ATX Motherboard from MSI is built on the Intel Z390 chipset with an LGA 1151 socket designed for 8th- and 9th-generation Intel Core, Pentium Gold, and Celeron processors. It's equipped with four DDR4 memory slots that support a max of 64GB of 4400 MHz RAM, two PCIe 3.0 x16 slots, four PCIe 3.0 x1 slots, six SATA III ports, and a single M.2 slot. With two PCIe 3.0 x16 expansion slots, this motherboard can be used for two-way AMD CrossFire setups. For storage, the M.2 slots support up to PCIe 3.0 x4 speeds as well as Intel Optane memory for quick data transfer. Please note that you should update the drivers and BIOS to the latest version before using Intel Optane memory. Other integrated features include multiple fan connectors, USB ports, VGA, DVI-D, and DisplayPort connectivity, Intel I219-V Gigabit LAN, and Realtek ALC892 7.1-channel HD audio.
    Cooling
  • The MPG Z390 has one water pump connector and six fan headers with DC and PWM control, which enable you to adjust your fans' speeds as needed within BIOS or a third-party software.
    User Friendly
    • XL Clip - Enlarged PCIe clips make it easier for users to swap out PCIe hardware
    • EZ Debug LED - Onboard LEDs for key components indicate the source of a problem
    CPU
  • For stability and performance, this motherboard features Core Boost, a combination of layout design and optimization which allows for faster and undistorted current delivery to the CPU. It also supports one-second overclocking with the optional MSI Game Boost software. Additional enhancements and features include load-line calibration, overvoltage protection, digital power design, and double power connectors.
    DDR4
  • The DDR4 RAM slots on this motherboard feature optimized traces and a fully isolated memory circuit for stable performance. It also supports a variety of RAM from different manufacturers, so be sure to check if yours is compatible. Moreover, you can easily toggle on XMP (Intel Extreme Memory Profile) with just a single click within BIOS.
    Storage
  • Install PCIe Gen 3 x4 SSDs or even Intel Optane memory on this motherboard for fast storage solutions. With a compatible drive, you'll be able to transfer data at speeds of up to 32 Gb/s. Moreover, you can enable XBoost within MSI's optional software for enhanced SSD speeds. For larger capacity storage, this motherboard has six SATA III ports and supports RAID 0, 1, 5, and 10 with M.2 Genie. Please note that you should upgrade the drivers and BIOS to the latest version before using Intel Optane memory.
    Internet Connectivity
  • Intel I219-V provides you with fast, optimized gaming-quality Gigabit LAN connectivity. Moreover, this motherboard has an E-key M.2 slot for an optional Intel CNVi Wi-Fi and Bluetooth module.
    Audio
  • The MPG Z390 is built with MSI Audio Boost as well as multiple hardware and software features designed to provide you with a better listening experience.
    • Dedicated, EMI-shielded Hi-Fi audio processor
    • Isolated audio design with LED border ensures a better audio signal
    • Separated audio layers for clean left and right channels
    • De-pop protection prevents loud popping sounds when you plug or unplug or devices
    • Nahimic 3 surround sound for immersion
    • High-quality audio capacitors for a warmer sound
    • Connectors for 7.1-channel surround sound
    MSI Mystic Light
  • Control and sync your compatible RGB products with MSI Mystic Light. This motherboard has a single 4-pin RGB LED connector for connecting compatible devices. With over 16.8 million colors to choose from and a variety of lighting patterns, MSI Mystic Light can be easily configured to fit your build's aesthetics.
UPC: 824142169544 In the Box MSI Z390-A PRO LGA 1151 ATX Motherboard
  • I/O Shield
  • 2 x SATA Cable
  • Limited 3-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the MSI Z390-A PRO LGA 1151 ATX Motherboard in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:


    User manual for MSI Z390-A PRO LGA 1151 ATX Motherboard can be downloaded below, so the upload option is not active.


    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%

    User manual for MSI Z390-A PRO LGA 1151 ATX Motherboard can be downloaded below, so the upload option is not active.

    Download User Manual

    The user manual for the MSI Z390-A PRO LGA 1151 ATX Motherboard can be downloaded in PDF format at the link stated below.
    Download PDF user manual - MSI Z390-A PRO LGA 1151 ATX MotherboardDownload PDF User Manual - https://www.search-manual.com/ upload/ msi-z390-a-pro-lga-1151-atx-motherboard-251313-user-manual.pdf
    (PDF file, 6.25 MB)


    Technical parameters

    MSI Z390-A PRO Specs

    Chipset Intel Z390
    CPU Socket LGA 1151
    USB 2 x USB 2.0 Type-A
    1 x USB 3.1 Gen 2 Type-A
    1 x USB 3.1 Gen 2 Type-C
    2 x USB 3.1 Gen 1 Type-A
    Display 1 x VGA
    1 x DVI-D
    1 x DisplayPort
    Audio 6 x 3.5 mm
    Ethernet / Controller 1 x Intel I219-V Gigabit
    PS/2 1 x Combo
    Memory Slots 4 x 288-Pin
    Memory Support DDR4 2133, 2400, 2666, 2800, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3733, 3866, 4000, 4133, 4200, 4266, 4300, 4400 MHz
    Maximum Capacity 64 GB
    Channel Architecture Dual Channel
    ECC Support Non-ECC Unbuffered
    SATA 6 x SATA III
    M.2 1 x M Key 2242, 2260, 2280, 22110 (PCIe 3.0 x4, SATA III)
    U.2 None
    Optane Memory Support Yes
    RAID Support RAID 0, 1, 5, 10 (SATA)
    Expansion Slots 2 x PCIe 3.0 x16
    4 x PCIe 3.0 x1
    USB 2 x USB 3.1 Gen 1 Header (Supports 4 USB Type-A Ports)
    2 x USB 2.0 Header (Supports 4 USB Type-A Ports)
    Multi-GPU Support 2-Way AMD CrossFireX
    Air Cooling 1 x 4-Pin CPU
    5 x 4-Pin System
    Liquid Cooling 1 x 4-Pin Pump
    Power Connectors 1 x 24-Pin Mainboard
    1 x 8-Pin CPU
    1 x 6-Pin ATX
    Security Chassis Intrusion, TPM Module
    LED Header 1 x RGB
    Audio None
    Diagnostics Clear CMOS, CPU Overclock
    Add-On 1 x Thunderbolt Card Header
    Legacy 1 x Serial
    1 x Parallel
    I/O Connection Headers AAFP, USB 3.1
    Audio Codec Realtek ALC892 (7.1-Channel)
    Module Support 1 E Key M.2
    Supported Operating Systems Windows 10 (64-Bit)
    Form Factor ATX
    Dimensions 9.6 x 12" / 243.84 x 304.80 mm
    Package Weight 2.71 lb
    Box Dimensions (LxWxH) 14.1 x 11.4 x 2.7"

    Rating

    20% users recommend this product to others. And what about you?
