Product description Provided by third party: The HD-6Pack series has been designed for OB operators and anyone who needs to trunk multiple uncompressed SDI signals over fiber. Never before has a multi-channel SDI-over-fiber system been so easy to use and so portable. In just one RU, you can transport up to 18 SDI signals up to 3 Gbps without compression on a few as one singlemode fiber. The HD-6Pack features LED's to indicate signal presence and optical link status.
Since the SDI signals are not compressed, the HD-6Pack can be used in conjunction with other Multidyne SDI transport components to create custom signal topographies including point-to-point and point-to-multipoint links.
The HD-6Pack features a 1:1 ratio between SDI signals and optical fibers. For facilities where fiber is abundant, this is, by far, the most econmical solution available.
The HD-6Pack as well as and the HD12Pack and HD-18Pack can be used as stand-alone devices or mounted in a 1RU unit. So whether you are optimizing your fibers within a permanent campus or studio infrastructure, linking an "A" and "B" OB unit together or getting the most out of available fibers at the stadium, they have you covered.
The HD-6Pack and HD-6Pack-ONE. Providing the easiest, the most portable and the most cost efficient way to move more full bandwidth HD-SDI video over distances up to 10 km on fewer fibers.
- Key Features
-
- Up to 18 SDI signals on 18 or ONE fiber
- Fiber transport from 19.4 Mbps to 3 Gbps
- Supports embedded audio and data
- Plug and Play
- Easy access to installed fiber infrastructures
- Small and portable
- Faster set and strike with fewer cables
Table of Contents
|
Upload User Manual
Have you got an user manual for the MultiDyne Portable Six-Channel 3G-SDI Transmitter over Single-Mode Fiber in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMultiDyne HD-6000-ONE-TX-ST Specs | | | Type | 3G-SDI/HD-SDI/SDI/ASI electrical to optic converter / distribution amplifier | | Width | 6.7 in | | Depth | 5.5 in | | Height | 1.8 in | | Weight | 16.01 oz | | | | Max Power Consumption | 20 W | | Low Voltage Power | DC 9 - 24 V | | | | Terminals | (6) x 3G HD-SDI output - BNC
(6) x SDI/ASI output (optical) - LC/UPC | | | | Min Operating Temperature | 32
