Product description The HDMI 4K over Cat5e/6 HDBT Wall Plate Extender Kit from MuxLab comes with a transmitter wall plate and a receiver wall plate. This UK version kit allows HDMI equipment to be connected up to 200' (60 m) at 1080p resolution, and up to 131' (40 m) at 4K 3840 x 2160/24 resolution via one Cat5e/6 unshielded twisted pair cable in a point-to-point configuration. - Supports 1080p deep color, 4K @ 30 fps, and 3D resolutions
- Up to 230' (70 m) via Cat5e cable
- Supports bidirectional IR
- Suitable for commercial and residential AV systems, classroom projector systems, digital signage, boardroom systems, collaborative PC systems, and medical information systems
UPC: 627699024515 In the Box MuxLab HDMI 4K over Cat5e/6 HDBT Wall Plate Extender Kit (UK Version) Set of Mounting Screws Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the MuxLab HDMI 4K over Cat5e 6 HDBT Wall Plate Extender Kit in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMuxLab 500451-WP-UK Specs | Bandwidth | 340 MHz | | Signals | HDMI 1.4a protocol | | Connectors | 1 x HDMI
1 x RJ45S, Cat5e/6 | | Maximum Distance | Cat5e/6:
230' (70 m) up to 1080p Deep Color
131' (40 m) for 4K; 3840 x 2160/24, 25 & 30 Hz | | RJ45 Pin Configuration | RJ45
Pin 1 (R) Pin 2 (T)
Pin 3 (R) Pin 6 (T)
Pin 4 (R) Pin 5 (T)
Pin 7 (R) Pin 8 (T) | | Power Supply | 1 x 110 - 240 VAC, 5 VDC power supply with interchangeable blades | | Power Consumption | 6 W for each side | | Operating Temperature | 32 to 104°F (0 to 40°C) | | Storage Temperature | -4 to 185°F (-20 to 85°C) | | Humidity | up to 95% non-condensing | | Enclosure | Metal Wall-Plate one gang | | Compliance | Regulatory: FCC, CE, RoHS | | Dimensions | 4.5 x 2.8 x 1.5" (11.4 x 7.1 x 3.8 cm) | | Weight | 1.6 lb (0.7 kg) |
