User Manual for MXR EVH117 Flanger Pedal Click to enlarge the picture
Contents of the user manual for the MXR EVH117 Flanger Pedal
- Product category: Effects Pedals MXR
- Brand: MXR
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for MXR Effects Pedals
 |
User manual for the MXR EVH117 Flanger Pedal contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any MXR product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official MXR user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a MXR product will considerably shorten its lifespan!
|
Product description The EVH117 Flanger from MXR is a variation of the classic MXR Flanger pedal that was introduced in the '70s and prominently featured on many recordings, offering a variety of analog sweeping space sounds and dynamic jet plane effects, short delays, chorus, and vibrato. The original modulation effect became a staple of many guitarists' rigs, and an integral part of the early Van Halen sound. This new customized version of the original MXR Flanger was developed as a collaboration between guitarist Eddie Van Halen and Dunlop's engineering team. Along with all of the same standard features of the original, the EVH117 offers a special EVH switch that instantly calls up Eddie's personal settings for "Unchained." Simply hit the switch for the same legendary effect! Like the original MXR Flanger pedal, the EVH117 features the same bucket-brigade technology to provide its magical sounds, and includes four tweakable parameters for conjuring up a plethora of effects and tonal textures: Manual sets the degree of phase shifting, Width adjusts the intensity of the time delay, Speed regulates the speed of the time delay, and Regeneration controls the intensity of the overall effect. The EVH117 Flanger is built inside a die-cast housing that's painted with EVH-style black and white striped graphics. A footswitch toggles the effect on or off, and a red LED indicates when the effect is on. A separate green LED indicates when the EVH switch has been engaged. The pedal is powered by two 9V batteries or an 18 VDC adapter such as the Dunlop ECB004/ECB004E, or Dunlop DCB10 Brick power supply (sold separately). UPC: 710137029651 In the Box MXR EVH117 Flanger Pedal Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the MXR EVH117 Flanger Pedal in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersMXR EVH117 Specs | Audio Input Jack | 1/4" (6.3 mm) | | Audio Output Jack | 1/4" (6.3 mm) | | Input Impedance | 470 kOhms | | Output Impedance | 1 kOhms | | Maximum Input Level | +5 dBV @ 1 kHz | | Maximum Output Level | +5 dBV @ 1 kHz | | Signal to Noise | >98 dB A-weighted (Vref 1 V RMS) with all controls at mid position | | Frequency Response | 20 Hz to 20 kHz | | Max Delay | 37.9 ms | | Max Phase Shift | 13.64 k deg. @ 1 kHz | | Noise Reduction | 2:1 ratio, optimum independent attack & recovery | | Rate Control | 0.1 Hz to 10 Hz | | Housing Material | Zinc | | Power Draw | 35 mA | | Power Requirement | 2x 9V batteries or Dunlop ECB-400 18 VDC adapter | | Dimensions (L x W x H) | 5.0 x 3.8 x 1.5" (13.0 x 9.7 x 3.8 cm) | | Weight | 1.5 lb (0.7 kg) | | | | Package Weight | 1.92 lb | | Box Dimensions (LxWxH) | 6.05 x 4.5 x 2.95" |
