Nebula SHiNYO P3D Single Smart Light

Search your instruction manual in PDF to download

User Manual for Nebula SHiNYO P3D Single Smart Light

Click to enlarge the picture
Nebula SHiNYO P3D Single Smart Light Contents of the user manual for the Nebula SHiNYO P3D Single Smart Light
  • Product category: LED Lights Nebula
  • Brand: Nebula
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for Nebula LED Lights

Nebula SHiNYO P3D Single Smart Light Nebula SHiNYO P3D Single Smart Light Nebula SHiNYO P3D Single Smart Light Nebula SHiNYO P3D Single Smart Light Nebula SHiNYO P3D Single Smart Light
User manual for the Nebula SHiNYO P3D Single Smart Light contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any Nebula product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official Nebula user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a Nebula product will considerably shorten its lifespan!



Product description

With a design that features a lightweight and compact form factor, the SHiNYO P3D Single Smart Light from Nebula is a bi-color LED panel providing soft, evenly distributed light with wide beam angle coverage of 120°. An optional P3D T-junction allows you to join two panels together for an expansive coverage of 240°. Housed inside a durable aluminum alloy shell that measures 11.8 x 11.8" and is only 0.8" in thickness, the dimmable light's 144 LEDs offer a color temperature range of 3300 to 5600K to match other light sources or ambient light conditions, while maintaining a CRI of 96 and TLCI of 98—an indicator of superior accuracy in the rendering of colors. The SHiNYO P3D's Li-Ion battery gives you approximately three to six hours of runtime on a full charge, with a flicker-free output that's ideal for photo or video.While you can make adjustments locally on the fixture, you can also make them wirelessly at distances up to 328' with a separately purchased Smart Watch that controls color temperature, brightness, and memory functions on its 1.5" touchscreen. The system supports 16 groups with 16 lights each, totaling 256 units. Optionally, you can use the Filmpower app for easy adjustments using your smartphone or tablet. The SHiNYO P3D ships with a handbag and a multi-voltage charger for worldwide use.
    Ultra-Thin Design and Rugged Aluminum Shell
  • The SHiNYO P3D measures 11.8 x 11.8" and is just 0.8" thick—slim enough to fit in almost any tight space. Its aluminum shell makes it durable and shock-resistant.
    Variable Color Temperature
  • Color temperature is variable from 3300 to 5600K, while maintaining a high CRI/TLCI rating of 96/98—an indicator of superior accuracy in color rendition.
    Built-In Li-Ion Battery
  • The SHiNYO P3D's 10,000 mAh Li-Ion battery will give you 3 to 6 hours of runtime on a full charge.
    Wireless Control
  • The Smart Light, brightness, color temperature, and memory functions can be controlled at distances up to 328' with an optional Smart Watch. It can also be adjusted on your smartphone or tablet with the Filmpower app. Up to 256 lights can be controlled via 16 channels with 16 groups.
    120° Beam Angle
  • The SHiNYO P3D's 120° beam angle offers wide coverage. Two lights can be joined together with an optional T-junction to increase coverage to 240°.
    4th Generation Light Guide Technology
  • The 4th Generation Light Guide Technology gives the SHiNYO P3D a 92% efficiency rating and soft, uniform light output.
UPC: 643451959253 In the Box Nebula SHiNYO P3D Single Smart Light
  • Charger
  • Handbag
  • Limited 1-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the Nebula SHiNYO P3D Single Smart Light in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Nebula Shinyo P3D Specs

    Beam Angle 120°
    Color Temperature 3300 to 5600K
    Color Accuracy Standard CRI 96
    TLCI 98
    Cooling System Passive
    Dimming Yes
    Display OLED Touchscreen
    Housing Material Aluminum
    Photometrics 86.2 fc / 928 lux at 3.28' / 1 m
    244.2 fc / 2629 lux at 1.64' / 0.5 m
    Number of LEDs 144
    Expected Lamp Life 150000 Hours
    Fixture Dimensions Flood: 11.8 x 11.8 x 0.9" / 300.0 x 300.0 x 22.0 mm
    Fixture Weight 4.85 lb / 2.2 kg
    Fixture Mount 5/8" Receiver
    Accessory Mount None
    Remote Control Type Wi-Fi, Proprietary Wireless
    Wireless Range 328.1' / 100 m
    Wireless Channels / Groups 16 / 16
    AC Input Power 100 to 240 VAC, 50 / 60 Hz
    DC Input Power 16.8 VDC at 3 A
    Power Source Integrated Battery
    Max Power Consumption 42 W
    Run Time 6 Hours at Low Power
    3 Hours at Full Power
    Operating Temperature -13 to 113°F / -25 to 45°C
    Package Weight 8.6 lb
    Box Dimensions (LxWxH) 18.2 x 15.7 x 4.9"
