User Manual for Neumann KM 133 D Modular Digital Microphone Click to enlarge the picture
Contents of the user manual for the Neumann KM 133 D Modular Digital
- Product category: Modular Microphone Components Neumann
- Brand: Neumann
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Neumann Modular Microphone Components
|
User manual for the Neumann KM 133 D Modular Digital contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Neumann product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Neumann user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Neumann product will considerably shorten its lifespan!
|
Product description The KM 133 D Modular Digital Microphone by Neumann is a pressure condenser microphone with an AES/EBU digital output and built-in A/D converter that utilizes the AES 42 standard. The mic uses the KK 133 omnidirectional, diffuse field equalized capsule, which is almost completely made of titanium. It is based on the microphones M 50, TLM 50 and M 150 Tube. As in those microphones, the capsule is provided with an SBK 133 sound diffraction sphere of 40mm in diameter. The sphere helps the frontal frequency response rise smoothly towards high frequencies, resulting in a flat diffuse field response. Taking the sphere off, the frontal frequency response is flat up to 6 kHz, above that frequency rising by 4 to 5 dB. The KM 133 D is equipped with an AES/EBU output and utilizes the AES 42 standard. The signal is converted from analog to 24 bit digital directly at the capsule. The KM 133 D is intended for use with the Neumann DMI-2 or DMI-8 digital microphone interfaces in conjunction with the Neumann RCS Remote Control Software. These two in tandem offer microphone powering with advanced remote control and monitoring features. Equipment that supports the AES 42 standard can process the output signal of the KM 133 D directly without the use of a DMI interface, but with limited remote control functionality that would be dependent on the AES 42 supported device. If your equipment does not support AES 42, you must use the Neumann DMI-2 or DMI-8 digital microphone interface. Neumann also offers the AES/EBU Connection Kit, a less expensive alternative to the DMI interfaces that does not support remote control functionality. - Digital Output From Mic
- Features a built-in A/D converter with 24-bit AES 42 digital output for use with the Neumann DMI-2 or DMI-8 digital microphone interfaces, the Neumann AES/EBU or S/PDIF Connection Kit, or direct connection to your AES 42 supported digital mixer
- Remote Control
- The digital output utilizes the AES 42 standard which allows for powering and software remote control and monitoring via the optional DMI-2 or DMI-8 interfaces
- SBK 133 Sound Diffraction Sphere
- Diffraction sphere that helps the frontal frequency response rise smoothly towards high frequencies, resulting in a flat diffuse field response
- Designed for Orchestral Applications
- The KM 133 D is particularly suited for orchestral and other ensemble recordings in acoustically pleasant spaces
In the Box Neumann KM 133 D Modular Digital Microphone SBK 133 Sound Diffraction Sphere Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Neumann KM 133 D Modular Digital Microphone in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersNeumann KK 133 D Specs | Transducer | Pressure transducer | | Polar Pattern | Omni Diffuse-Field Equalized | | Frequency Range | 20 Hz - 20 kHz | | Sensitivity | -40 dBFS | | Equivalent Noise | 28 dB, CCIR
15 dB-A, A-weighted | | Signal-to-Noise Ratio | 66 dB, CCIR
79 dB, A-weighted | | Maximum Input Sound Level | 134 dB @ 0 dBFS | | Power Requirements | Phantom power complying with AES 42 | | Current Consumption | Max. 150 mA (DPP) | | Output Connectors | XLR-3M Type - AES/EBU 42 Standard | | Dimensions | 5.03 x 0.87" (128 x 22 mm) | | Weight | 4.16 oz. (118 g) |
