User Manual for Neumann SKM 150 Stereo Microphone Set Click to enlarge the picture
Contents of the user manual for the Neumann SKM 150 Stereo Microphone Set
- Product category: Small Diaphragm Condenser Neumann
- Brand: Neumann
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Neumann Small Diaphragm Condenser
|
User manual for the Neumann SKM 150 Stereo Microphone Set contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Neumann product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Neumann user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Neumann product will considerably shorten its lifespan!
|
Product description The SKM 150 from Neumann is simply a stereo combination set consisting of 2 KM 100 phantom power supply/output stages, 2 AK 50 hyper-cardioid microphone elements. STH 100 stereo mount and dual windscreens are included and stored in a wooden jeweler's case.The KM 100 is powered via 48 Volt phantom power and is designed for quick connection to all compatible elements and accessories. The KM 100 uses transformer-less circuitry resulting in high-output capability and low self-noise. The balanced XLR output is protected against radio frequency interference. The entire microphone circuitry is built into the capsule on a single hybrid module measuring 2cm in area. The result is a compact, interchangeable output stage providing pristine output signal without any coloration.The AK 50 microphone element features a pressure-gradient, single-diaphragm transducer with a hyper-cardioid polar pattern. The hyper-cardioid polar pattern is highly effective in reducing off-axis ambiance and noise. Attenuation of sound from the side or rear is about 10 dB with the least sensitivity at an angle of 120 degrees. This allows the element to be used in recording and sound-reinforcement applications, in front of stage monitors or instrument miking. - Stereo Set
- The combinaton of dual AK 50 hyper-cardioid microphones allows stereo capturing in either X/Y or M/S configurations. The provided STH 100 stereo mount provides adequate mounting for both microphone and power supply.
- Modular Design
- The KM 100 is modular allowing compatible, interchangeable elements to be used depending on the application. The capsule is powered via 48V phantom power.
- Pristine Output Signal
- Transformerless design and custom circuitry provide a pristine, low noise, high-output character to signal at the KM 100 output stage.
- Stereo Mount
- The microphone set includes the accessory STH 100 stereo mount. The mount allows accurate mic placement for X/Y style capturing.
UPC: 615104070998 In the Box Neumann SKM 150 Stereo Microphone Set 2x AK 50 Hyper-Cardioid Active Capsules 2x KM 100 Output Stages WNS110 Foam Windscreen for KM Series Microphone scswybfrdddswssvsysrebxabydvssev SG21/17MT Swivel Mount with Clamp for 21mm Mics Wooden Jeweler's Case Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Neumann SKM 150 Stereo Microphone Set in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersNeumann SKM 150 Specs | | | Operating Principle | Pressure Gradient | | Polar Pattern | Hypercardioid | | Frequency Range | 20 Hz to 20 kHz | | Signal to Noise Ratio | 67 dB CCIR
76 dB A-Weighted | | Equivalent Noise Level | 27 dB CCIR
18 dB A-Weighted | | Maximum SPL | 142 dB SPL | | Pad | -10 dB | | THD | 0.5% | | Impedance | 50 Ohms | | Load Impedance | 1000 Ohms | | Sensitivity | 10 mV/Pa at 1 kHz into 1 kOhms | | | | Output Connectors | 1 x 3-Pin XLR | | Operating Current Consumption | 2 mA | | Operating Voltage | 48 V ± 4 V | | Length | 3.62" / 92 mm | | Diameter | 0.87" / 22 mm | | Weight | 2.82 oz / 80 g | | | | Package Weight | 3.56 lb | | Box Dimensions (LxWxH) | 13.0 x 9.5 x 3.0" |
