User Manual for Neutrik NAC3MPB-1 Power-Out Male Chassis Connector Click to enlarge the picture
Contents of the user manual for the Neutrik NAC3MPB-1 Power-Out Male Chassis Connector
- Product category: Adapter Cables & Connectors Neutrik
- Brand: Neutrik
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Neutrik Adapter Cables & Connectors
|
User manual for the Neutrik NAC3MPB-1 Power-Out Male Chassis Connector contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Neutrik product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Neutrik user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Neutrik product will considerably shorten its lifespan!
|
Product description The Neutrik NAC3MPB-1 Power-Out Male Chassis Connector features a powerCON locking 3-conductor equipment AC connector with contacts for line, neutral, and pre-mating ground contact. It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed in order to ensure a safe power connection. Note: The PowerCon is a connector without a breaking capacity and should not be connected or disconnected under load or live. - Locking 20A / 250 VAC appliance coupler
- 3 contacts for line, neutral, and pre-mating safety ground
- Possibility of intermating eliminated with different functional power-in and power-out versions
- Fast and easy twist lock latching system
- User friendly latch design for easy handling
- UL, cUL recognized components
In the Box Neutrik NAC3MPB-1 Power-Out Male Chassis Connector Limited 6-Month Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Neutrik NAC3MPB-1 Power-Out Male Chassis Connector in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersNeutrik NAC3MPB-1 Specs | | | Contact Resistance | Inner: ≤3 mΩ | | Dielectric Strength | 4 kVDC / 2.8 kVDC | | Insulation Resistance | >0.1 GΩ (after damp heat test IEC 68-2-30) | | Contacts | Electronical: 2 + PE | | Rated Current Per Contact | 20 A rms | | Rated Voltage | 250 VAC | | | | Lifetime | >1000 mating cycles | | Locking Device | Quick lock | | Mounting Direction | Front | | Chassis Shape | D | | | | Contact Plating | 2 µm Ag | | Locking Element | Stahl Ck67 | | Shell | Polyamide (PA 6.6 30 % GR) | | Contacts | Bronze (CuNi1Si0.2) | | | | Flammability | UL 94 V-0 | | Temperature Range | -22 to 176°F (-30 to 80°C) | | Coding System | Product Specific: B-type for power outlet (color coding gray) | | Dimension (D x W x H) | 1.47 x 1.02 x 1.22" (37.2 x 26 x 31 mm) | | | | Package Weight | 0.01 lb | | Box Dimensions (LxWxH) | 1.0 x 1.0 x 1.0" |
Rating100% users recommend this product to others. And what about you?
This product has already been rated by 20 owners. Add your rating and experience with the product.
