User Manual for Neutrik NL8MPR SpeakON Panel Mount Connector Click to enlarge the picture
Contents of the user manual for the Neutrik NL8MPR SpeakON Panel Mount Connector
- Product category: Audio Connectors Neutrik
- Brand: Neutrik
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Neutrik Audio Connectors
|
User manual for the Neutrik NL8MPR SpeakON Panel Mount Connector contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Neutrik product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Neutrik user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Neutrik product will considerably shorten its lifespan!
|
Product description Featuring an 8-pole chassis connector, nickel metal square G-size flange, and countersunk thru holes, the Neutrik NL8MPR Panel Mount Connector for SpeakON termination points is the standard connector for loudspeaker and amplifier interconnections. It features a metal locking system which only makes contact once the mechanism is fully locked. With its airtight design, glass-reinforced construction, and precise keyway, this speakON receptacle is quite robust and dependable. Note: SpeakON is NOT to be used as an AC mains or power supply connector! - Glass-reinforced materials
- Precise keyway for secure mating
- Accurate twist-lock latching system
- Airtight design, suitable for speaker applications
UPC: 736902401194 In the Box Neutrik NL8MPR SpeakON Panel Mount Connector Limited 180-Day Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Neutrik NL8MPR SpeakON Panel Mount Connector in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersNeutrik NL8MPR Specs | Connection Type | SpeakON | | Gender | Male | | | | Contact Resistance | ≤ 3 MOhms inner (after lifetime) | | Dielectric Strength | 4 kVDC (peak) | | Insulation Resistance | > 1 GOhm (after damp heat) | | Rated Current Per Contact | 30 A rms continuous
40 A audio signal, duty cycle 50 % | | Rated Voltage | 250 V (Insulation) | | | | Lifetime | > 5000 mating cycles | | Locking Device | Quick lock | | Chassis Shape | Square G-size flange | | Layout | 4 thru holes | | Contact Plating | 4 µm (Ag) | | Contacts | Bronze (CuSn6) | | Shell | Polyamide (PA 6 30 % GR) Ni | | | | Flammability | UL 94 HB | | Solderability | Complies with IEC 68-2-20 | | Temperature Range | -22 to 176°F / -30 to 80°C | | | | Package Weight | 0.1 lb | | Box Dimensions (LxWxH) | 1.3 x 1.1 x 0.8" |
Rating100% users recommend this product to others. And what about you?
This product has already been rated by 14 owners. Add your rating and experience with the product.
