Product description The Neutrik powerCON NAC3MPA-1 to powerCON NAC3MPB-1 Coupler for Linking Cables is a locking 3 conductor equipment AC connector with contacts for line, neutral, and pre-mating ground contacts. This device replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed in order to ensure a safe power connection. The PowerCON is a connector without breaking capacity. It should not be connected or disconnected under load or live. - PowerCON NAC3MPA-1 (power in) to PowerCON NAC3MPB-1 (power out)
- Lockable 3 pole equipment (AC) connector
- High current capacity, rated at 20A / 250VAC
- Color coded for easy identification, powerCON offers power-in (blue) and power-out (grey) versions with different keying to avoid the possibility of intermating
- Fast and easy locking system
- Extremely robust and reliable
- Excellent cable retention
- UL, cUL recognized components (file no. E 135070) VDE certified (Reg. No. 6360), SEV approved (No. 96.1 10096)
- Redesigned latch for easier handling and secure locking
- Coupler for linking cables (couples NAC3FCA to NAC3FCB)
In the Box Neutrik powerCON NAC3MPA-1 to powerCON NAC3MPB-1 Coupler for Linking Cables Limited 6-Month Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Neutrik powerCON NAC3MPA-1 to powerCON NAC3MPB-1 Coupler for Linking Cables in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersNeutrik NAC3MM-1 Specs | | | Connection Type | Adapter | | Gender | Male | | | | Contact Resistance | ≤3 mΩ (inner) | | Dielectric Strength | 4 kVDC | | Insulation Resistance | >0.1 GΩ (after damp heat test IEC 68-2-30) | | Rated Current Per Contact | 20 A rms | | Rated Voltage | 250 VAC | | | | Lifetime | >1000 mating cycles | | Locking Device | Quick lock | | | | Contact Plating | 2 µm Ag | | Locking Mechanism | Steel Ck67 | | Contacts | Bronze (CuNi1Si0.2) | | Shell | Polyamide (PA 6.6 30 % GR) | | | | Flammability | UL 94 V-0 | | Protection Class | IP 20 (mated) | | Safety | EN/IEC 61984 | | Solderability | Complies with IEC 68-2-20 | | Temperature Range | -22 to 176° F (-30 to 80°C) | | Overall Dimensions (WxHxD) | 1.024 x 3.11 x 1.22" (26 x 79 x 31 mm) | | | | Package Weight | 0.2 lb | | Box Dimensions (LxWxH) | 2.0 x 0.5 x 0.5" |
