Product description The NVS 27M 1x 3rd Generation Compact Night Vision Clip-On from Newcon Optik converts your day riflescope into a night vision device. It features a 3rd generation intensifier tube with a Gallium Arsenide photocathode, manual gain, resolution of 64 lp/mm, and a SNR of 25. The 3rd generation image intensifier tube utilizes an autogated power supply that provides outstanding performance and enables operation in high-light conditions, slows-down degradation, and helps extend life of the device. The optical system is designed to accommodate daytime riflescopes with magnification range of 1-20x and offers a 78mm objective lens with f/1.15 F-stop. The optical system also offers a 12° angular field of view and a 33' minimum focus distance. The unit is powered by the included lithium-ion CR-123A battery. The aluminum housing is lightweight, durable, waterproof submersible to 33', and resistant to extreme temperatures. - Intensifier Tube and Illuminator
-
- 3rd generation
- Autogated supply
- Manual gain control
- Resolution of 64 lp/mm, and an SNR of 25
- ABC-Automatic Brightness Control
- Optical Performance
-
- Magnification: 1x
- Accommodates scopes with 1-20x magnification
- Lens system: 78mm, f/1.15
- Field of view: 12°
- Close focus: 33'
- Exit pupil 42mm
- Construction Details
-
- Compatible with Picatinny rails
- Withstands extreme temperatures
- Flip-out lens covers
- Filled with nitrogen
- Waterproof, submersible to 33'
In the Box Newcon Optik NVS 27M 1x 3rd Generation Compact Night Vision Clip-On - Objective Lens Cap
- Soft Carrying Case
- Lens Cleaning Kit
- Limited 1-Year Warranty
Table of Contents
|
Upload User Manual
Have you got an user manual for the Newcon Optik NVS 27M 1x 3rd Generation Compact Night Vision Clip-On in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersNewcon Optik NVS 27M Specs | Intensifier Tube | 3rd generation
Autogated
Manual gain control
Gallium Arsenide photocathode
Resolution: 64 lp/mm, SNR: 25
Figure of merit: 1600
Photocathode sensitivity: 1800 mAh
Mean time to failure: 10,000 h | | Magnification | 1x | | Angular Field of View | 12° | | Lens System | Objective: 78mm
f/1.15 | | Exit Pupil Diameter | 42 mm | | Minimum Focus Distance | 33' (10 m) | | Infrared Illuminator | Optional | | Battery / Runtime | 1 x AA battery / 60 h max
1 x CR-123A battery / 60 h max | | Weatherproofing | Waterproof, submersible to 33' (10 m) for 60 min | | Operating Temperature | -67 to 149°F (-55 to 65°C) | | Storage Temperature | -76 to 158°F (-60 to 70°C) | | Dimensions | 8.6 x 3.5 x 3.4" (220 x 90 x 87 mm) | | Weight | With mounting bracket: 34.2 (970 g)
Without mounting bracket: 20.1 oz (570 g) |
