User Manual for Newcon Optik NVS 6-3 XT 1x25 Aviator Night Vision Binocular Click to enlarge the picture
Contents of the user manual for the Newcon Optik NVS 6-3 XT 1x25
- Product category: Night Vision Binoculars Newcon Optik
- Brand: Newcon Optik
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Newcon Optik Night Vision Binoculars
|
User manual for the Newcon Optik NVS 6-3 XT 1x25 contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Newcon Optik product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Newcon Optik user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Newcon Optik product will considerably shorten its lifespan!
|
Product description The NVS 6-3 XT from Newcon Optik is an aviation-style night vision binocular. Configured with two objectives, two oculars, and dual 3rd generation image intensifiers - this NVS 6 is capable of outstanding stereoscopic night vision imagery. Depth perception is a crucial concern - and this goggle offers spectacular three dimensional viewing in a cost effective, feature laden package. This lightweight unit is a multi-use professional system that offers versatility and performance that can't be matched with a single-tube design. The NVS 6 is fitted with high-quality lenses that provide a clear sharp line of sight; while the impressive 3rd gen intensifier tubes deliver a remarkable resolution above 64 lp/mm. The NVS 6 comes complete with a fully adjustable mounting system that's compatible with Gallet helmets. There are many variables that affect the distance that one can see with a night vision device; the object's size, ambient weather and lighting conditions, the level of detail needed for recognition, etc. The important factors to consider when evaluating any night vision device are the generation of the intensifier tube along with its specified resolution and s/n ratio. The magnification, clarity, and light transmission performance of the NVD's optics also contribute to its low/no-light performance capabilities. All NVDs sold by feature bright-light protection systems. However, this does not mean that bright light can/will not damage the device. Exposure to bright light compromises the longevity and performance of image intensifier tubes. Note: Export of this device described herein is strictly prohibited without a valid export license issued by the U.S. Department of State office of Defense Trade Controls, as prescribed in the International Traffic in Arms Regulation (ITARrrdebrqedswaxy), Title 22, Code of Federal Regulation, Parts 120-130, and/or the U.S. Department of Commerce. For further information contact the Office of Defense Trade Control and/or the U.S. Department of Commerce. - Low battery indicator on helmet mount
- Helmet Mount Adjustments
- Vertical: 1.6 cm total travel Fore/aft: 2.7 cm total travel Eye-span: 5.2-7.2 cm Tilt: 10° total travel
- Third Generation Intensifiers
- Resolution: 57-64 lp/mm Third generation intensifiers last longer and deliver brighter images with greater detail and less distortion than previous generations of night vision technology.
In the Box Newcon Optik NVS 6-3 XT 1x25 Aviator Night Vision Binocular Soft Carry Case Gallet Helmet Mount Power Pack Lens Tissue Screwdriver 4 x "AA" Batteries Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Newcon Optik NVS 6-3 XT 1x25 Aviator Night Vision Binocular in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersNewcon Optik NVS-6 Specs | Intensifier Tube | Third generation | | Magnification | 1.0x | | Linear Field of View | 2184' @ 1000 yd / 725 m at 1000 m | | Minimum Focus Distance | 11.0" / 28 cm | | Eye Relief | 2.5 cm | | Dioptric Correction | +2/-5 | | Interpupillary Adjustment | 5.2-7.2 cm | | Lens System | 27mm f/1.23 | | Infrared Illuminator | Yes | | Battery / Runtime | 2 "AA" batteries | | Weatherproofing | Weather resistant | | Temperature Ranges | Operating: -25 to 126°F / -32 to 52°C | | Dimensions | 4.9 x 5.0 x 4.4" / 12.6 x 12.8 x 11.1 cm | | Weight | 1.3 lb / 570 g | | | | Package Weight | 4.0 lb | | Box Dimensions (LxWxH) | 14.0 x 14.0 x 10.0" |
