User Manual for NewTek TriCaster 40 V2 Software Upgrade Click to enlarge the picture
Contents of the user manual for the NewTek TriCaster 40 V2 Software Upgrade
- Product category: Switcher Software NewTek
- Brand: NewTek
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for NewTek Switcher Software
|
User manual for the NewTek TriCaster 40 V2 Software Upgrade contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any NewTek product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official NewTek user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a NewTek product will considerably shorten its lifespan!
|
Product description The NewTek TriCaster 40 V2 Software Upgrade brings new functionality to the TriCaster 40 live production studio that allows you to create a polished live production. This is the software upgrade and does not include the NewTek 40 hardware. With the included Animation Store Creator, you can create and customize effects and transitions with full color motion overlays with audio, and even map video on top of 3D surfaces. The dedicated title station works within the TriCaster features hundreds of preloaded templates and vector based drawing tools. The upgrade also expands the video formats that you can utilize, and allows you to capture to disk and also export to external applications. featuring improved control over white, black and color levels for all the inputs, the upgrade is more than just a slight feature bump.
The TriCaster 40 features 4 independent analog inputs for SD and HD video, it also features two live sources via the built-in Gigabit connector. This is a live production switcher with 14 channels that streams in HD, while allowing you to record your output stream. You can even access and key your talent into virtual sets, all live and in real time. The TriCaster 40 can record up to 20 hours of HD video on its internal drive, with the option to record the program output, Aux, or any of the Input Sources. - Four simultaneous live video sources, in any combination of HD Component, SD Component, Y/C or Composite.
- Independent frame synchronizers, keying, cropping, Proc Amp and white balance controls on each video input.
- Two network sources over Gigabit, with keying, cropping, Proc amp and white balance controls on each input.
- Integrated DDR and two graphic sources
- Stream HD live, via Adobe Flash or Microsoft Windows Media Push/Pull
- Two downstream keyers with independent DVE, and scaling.
- Four independent, mix/effect-style channels supporting multi-source compositions, virtual sets, double-box effects.
- Three configurable sources per channel, each with independent positioning, scaling and cropping, including upstream keyer with DVE and transition controls.
- Up to 5 video layers on the screen at the same time
- Integrated multi-channel audio mixer for internal and external audio sources, output, stream and headphones
- Integrated TransWarp effects engine on all effects channels supports standard transitions, customizable Animation Store Creator transitions with audio, and overlay effects.
- 24 HD live virtual sets, with multiple camera angles, real-time reflections, specular highlights, animated zoom and presets.
- Record in resolutions up to 1080p.
- Source selectable from among Program, Aux, or any single camera input.
- Select from QuickTime, Mpeg-2, Avi and H.264.
- Records up to 20 Hours of 1080i footage, using the internal storage. Longer record times are available by using external media drives.
Table of Contents
|
Upload User Manual
Have you got an user manual for the NewTek TriCaster 40 V2 Software Upgrade in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersNewTek FG-000419-R001 Specs | Supported Formats | 1080/30p, 1080/24p, 1080/60i, 720/60p, 720/30p, 720/24p, 480i (16:9), 480i (4:3) | | Playback Media Formats | AVI, DV, DVCPro, DVCProHD, FLV, F4V, H.263, H.264, MOV, MKV, MJPEG, MPEG (1, 2, all profiles, program or transport streams), MP4, WMV, WebM, PSD, PNG, TGA, BMP, JPEG, EXR, RAW, TIF, AIFF, MP3, WAV, and more, with Import Media application for batch import with optional transcoding of files (including Apple ProRes) | | OS Compatibility | The upgrade only works with your original TriCaster 40 system. |
Rating80% users recommend this product to others. And what about you?
This product has already been rated by 17 owners. Add your rating and experience with the product.
