User Manual for Novatron 2103FC Fan-Cooled Bare Tube Lamphead Click to enlarge the picture
Contents of the user manual for the Novatron 2103FC Fan-Cooled Bare Tube Lamphead
- Product category: Power Pack Heads Novatron
- Brand: Novatron
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Novatron Power Pack Heads
|
User manual for the Novatron 2103FC Fan-Cooled Bare Tube Lamphead contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Novatron product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Novatron user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Novatron product will considerably shorten its lifespan!
|
Product description The Novatron 2103FC Fan-Cooled Bare Tube Lamphead is a 3-way switching convertible flash head that contains the controls to independently ratio the flash and modeling lamp at full, -1 stop, or -2 stops. It comes equipped with an internal fan, which aids in cooling electronics and the user replaceable plug-in flashtube. Fan cooling extends the power handling capacity of this lamphead to 1500 watt/seconds. Without the fan in use, the power limit is 1000 watt/seconds. This head also gives the photographer the option of using different reflectors. This head is better for photographers who want more control over their light than what can be achieved with the other lampheads in the Novatron line of quality flash equipment. A power supply for this flash head is required. - Compact Design
- All Novatron Lampheads feature a umbrella socket for optimized and even light distribution.
- Easy to Control
- This lamp head features an integrated tilt mechanism for continuous tilting for stand or suspension mounting. An optional lever handle 4049, is available for even more precise control.
- Easily Replaceable Flashtube
- The plug-and-play flashtube eliminates the need to replace the entire head when the flashtube expires.
- Removable Reflector
- The 2103FC Lamphead can accept the included 2032 6.5" Removable reflector or an optional 16" 2043 reflector.
- Long-Reaching Cable
- 25' cable included. Head extension cables are available in 15 and 25' for heads used at longer distances from the power pack (Longer cable lengths will result in .25 and .3 stop reduction in power, respectively).
- Modeling Light
- Easily replaceable, 250W, quartz halogen
UPC: 053661099548 In the Box Novatron 2103FC Fan-Cooled Bare Tube Lamphead 1500 W/S Flashtube 6-1/2" Reflector, 70 Degrees - Novatron Bare Tube Head 250W/120V Modeling Lamp Head Extension Cable (25') Flashtube protector sleeve Stand Adapter 1 Year Manufacturer's Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Novatron 2103FC Fan-Cooled Bare Tube Lamphead in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersNovatron 2103FC Specs | Maximum Watt/Seconds | 1500/1000 | | User Replaceable Flashtube | Yes (F0008) | | Changeable Reflector | Yes | | Circuit Protection | No | | Cable Length | 25' (11.3 m) | | Modeling Light Wattage | 250W, 120V | | Modeling Light On/Off Switch | Yes | | Protective Glass Dome | Yes | | Fan Cooled | Yes - Fan Off decreases head power limit to 1000 w/s | | Dimensions | 4 x 7" (10.1 x 17.8 cm) without reflector | | Weight | 3.2 lb (1.5 kg) | | | | Package Weight | 6.8 lb | | Box Dimensions (LxWxH) | 16.1 x 12.6 x 8.6" |
