Product description - PT01 Scratch Review with Swiftstyle
The Numark PT01 Scratch is a durable portable turntable designed for the turntablist on the go. The deck can be used to complement any portable PA system, to listen as a standalone, or for impromptu performing. The PT01 Scratch is a compact AC- or battery-powered turntable with an accurate belt-drive motor. The integrated scratch switch allows any turntablist to perform anywhere. The switch can be adjusted for left or right handed use and is user replaceable. The USB output provides a direct connection to computers for archiving vinyl. A built-in speaker enables monitoring right from the turntable and line-level RCA output connections, which allow the PT01 Scratch to be connected into any line-level input.Line-level output eliminates the need for an amplifier with a phono input and is useful for direct connection to CD recorders, soundcards in computers, etc. Additional outputs include 1/4" headphone and 1/8" mini headphone outputs. The PT01 Scratch is an ideal solution for the mobile turntablist for performance or crate digging. -
- Built-in adjustable Scratch slide-switch
- User-replaceable Scratch slide-switch keeps the action going
- Protective dust cover and integrated carrying handle
- Wall-powered with included AC adapter or six batteries (not included)
- Built-in speaker
- Cartridge included
- Removable slipmat
- Class-compliant USB connection for computer recording
- Includes EZ Converter vinyl recording software
- 33 1/3, 45 and 78 RPM settings
- RCA line and headphone outputs
- 1/8" aux input with adjustable volume
UPC: 676762316415 In the Box Numark PT01 Scratch - Portable Turntable with DJ Scratch Switch USB Cable Power Adapter Software Download Card Cartridge Slipmat Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Numark PT01 Scratch - Portable Turntable with DJ Scratch Switch in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersNumark PT01 Scratch Specs | Minimum System Requirements (Mac) | Mac OS X 10.4.x USB 1.1 port | | Minimum System Requirements (PC) | Windows 2000/XP/Vista USB 1.1 port | | USB | Class compliant | | Connections | 2 x RCA line-level output (stereo pair)
1 x 1/4” / 6.35 mm stereo headphone output
1 x 1/8” / 3.5 mm stereo headphone output
1 x 1/8” / 3.5 mm stereo input
1 x USB port (stereo audio out) | | Speed | 33 1/3, 45, 78 rpm (45 rpm adapter included) | | Controls | Pitch, tone, gain, volume, RPM, Scratch-switch, power
Scratch-switch can be re-positioned by using a #5 screwdriver (screws have a 0.12" / 3.00 mm diameter) | | Power | Power Adapter: 12 VDC, 500 mA, center-positive
Batteries: 6 x D-cell | | Dimensions (W x D x H) | 11.9 x 11.9 x 4.0" / 302.3 x 302.3 x 101.6 mm | | Weight | 4.7 lb / 2.1 kg | | | | Package Weight | 6.5 lb | | Box Dimensions (LxWxH) | 17.7 x 14.4 x 5.7" |
