User Manual for Occipital Skanect Pro 3D Scanning Software Click to enlarge the picture
Contents of the user manual for the Occipital Skanect Pro 3D Scanning Software
- Product category: 3D Scanners Occipital
- Brand: Occipital
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Occipital 3D Scanners
|
User manual for the Occipital Skanect Pro 3D Scanning Software contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Occipital product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Occipital user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Occipital product will considerably shorten its lifespan!
|
Product description Capture a full color 3D model of an object, a person, a room, create 3D meshes out of real scenes, and more using Skanect Pro from Occipital. This software allows users to turn their Occipital Structure Sensor, Microsoft Kinect, or ASUS Xtion Pro Live into a 3D scanner that can operate at up to 30 fps.
With this software, users will be able to export .obj, .ply, .stl, and .vrml files, automate watertight repairs, simplify complex geometries, perform precise edits, export to online sharing platforms and printing services, and more. Occipital's Skanect Pro is compatible with Windows 7 or later and Mac OS 10.10 and later. General Features - Scan at up to 30 fps
- Skanect can acquire dense 3D information about a scene at up to 30 fps. Just move around your Structure Sensor, Kinect, or Xtion to capture a full set of viewpoints, and you will get a 3D mesh in real time.
- User-Friendly
- Skanect makes it easy to 3D scan different kind of scenes by providing a set of pre-defined scenarios, suitable for most use cases. You can then share your models online in a few clicks.
- Low Cost
- Skanect leverages consumer-grade 3D cameras like the Structure Sensor, Microsoft Kinect, and ASUS Xtion, limiting the hardware cost to a fraction of previous 3D scanning solutions. For a personal and hobbyist use, you can even download a free version of Skanect.
End-to-End 3D Scanning 3D Capture - Recording presets for body, object, and room scanning.
- Live feedback in low-, medium-, or high-quality.
- CPU- or GPU-accelerated reconstruction.
- Record timer & countdown.
- Full-scan or keyframe-only recording.
- 3D Processing
- Model simplification.
- Hole filling & watertight mesh generation.
- Plane cropping for optimal 3D prints.
- Colorization (with optional inpainting of unseen areas).
3D Sharing - Save full-resolution models (free version limited to 5000 faces).
- Export to 3D software and 3D printers that use .stl, .obj, .ply, and .vrml.
- Direct upload to Sketchfab and Shapeways.
Advanced Features - Color texture maps (.stl & .obj).
- External editing in 3rd party software (such as Meshlab or Meshmixer).
- Offline, non-real time reconstruction, allowing for increased quality on lower-end machines.
Compatible 3D Sensors - 3D Scan Wrielessly from an iPad to Skanect
- The Structure Sensor can be used for wireless 3D scanning, indoor mapping, augmented reality gaming, and more. It is also available for a USB Hacker Cable for wired connections to Windows, Mac, Android, and Linux. Wireless scanning is compatible with the 9.7" iPad Pro, 12.9" iPad Pro, iPad (5th Generation), iPad Air 2, iPad Air, iPad (4th Generation), iPad mini 2, iPad mini 3, and iPad mini 4.
Sensor Setup - Structure Sensor | ASUS Xtion | Primesense Carmine
- Windows
Download and install OpenNI 2 32- or 64-bit.
Mac
No extra setup necessary. - Kinect (Windows & Xbox)
- Windows
Download and install the Kinect for Windows SDK.
Mac OS X
No extra setup necessary. - Kinect Compatibility
- The Kinect for Windows sensor is not supported in Skanect for Mac. The Kinect for Xbox 360 sensor cannot be used commercially. The Kinect for Xbox One and Kinect for Windows V2 sensors are NOT supported.
Additional Setup - Mac OS X
- Only for NVIDIA GT 650 M or better: Download and install Mac CUDA Drivers to enable GPU reconstruction.
- Windows
- No additional setup is necessary, but make sure your NVIDIA drivers are current if you want to benefit from GPU reconstruction.
UPC: 811577020243 In the Box Occipital Skanect Pro 3D Scanning Software 1-Year of Minor Product Updates Table of Contents
|
Upload User Manual
Have you got an user manual for the Occipital Skanect Pro 3D Scanning Software in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersOccipital SKN01 Specs | | | CPU Reconstruction | 2 GB RAM, Quad-Core processor | | GPU Reconstruction | 2 GB RAM, Intel Core 2, and Cuda 2.0 compatible graphics card with 1 GB of memory | | Minimum Requirements | Windows: Windows 7 (64-bit) or later, Intel i7 CPU, 4 GB RAM, NVIDIA GTX 560 or higher
Mac: OS 10.10, MacBook Pro 2012 or MacBook Air 2013 | | | | Package Weight | 0.015 lb | | Box Dimensions (LxWxH) | 5.95 x 3.5 x 0.3" |
Rating80% users recommend this product to others. And what about you?
This product has already been rated by 22 owners. Add your rating and experience with the product.
Discussion
Ask our technicians if you have a problem with your settings,
or if anything is unclear in the user manual you have downloaded.
You can make use of our moderated discussion.
The discussion is public and helps other users of our website who may be encountering similar problems.
Post new comment to Occipital Skanect Pro 3D Scanning Software
| Subject: Query -- Scanect Pro | | Date: 03.04.2021 08:41:26 | Name: Sam Quintanar | Where can I find the instructions on how to use Scanect Pro with Structure Core to scan small robot parts?; considering getting $499 Bundle.
My computer is:
Win10 64-bit,
USB 2.0,
16GB Ram,
without CUDA capability;
can I still get quality digital 3D models with this computer? It seems like CUDA may be required. | | Post reply |
