Product description

• C12250001 120EX Standard Film Fluid Head (Black) The OConnor 120EX Standard Assembly C12250001 is the flagship of fluid head design. With a payload capacity of 120 lbs it is the right choice for larger format film and video cameras. This device features 90 to 90 degree tilt with a folding crank handle with numerical readout for repeatable counterbalance adjustments. This head features the EX Mode which allows extended weight capacity.
  Counterbalance System
  • The fluid head features a counterbalance system that will keep the camera from falling forward or backward when it is tilted. With the correct counterbalance, the camera will stay where you put it, throughout the entire +/-90° tilt range.
  Infinitely Adjustable True Fluid Drag
  • Fluid drag allows you to pan and tilt smoothly, without shake or vibration. The high viscosity fluid acts as a buffer, adding an adjustable level of resistance to the camera movement.
  Unmatched Versatility
  • The fluid head employs a modular design concept that allows you to choose different mounting bases (150mm, Mitchell, Sachtler/Vinten), quick release platforms (Oconnor, 120mm Euro, Panavision Dovetail and Arriflex Plates) and handles for added flexibility.
  EX-Technology
  • EX fluid heads can go far beyond that maximum payload by slowly limiting tilt range as the payload is increased. With the example of the 120EX, the payload for a 90° tilt range is between 30-120 lbs (14-54 kg), but in EX mode the 120EX can counterbalance up to incredible 240 lbs (109 kg) at a tilt range of 60°; all based on a 8" center of gravity.
• C12210001 Cine HD Aluminum Alloy Tripod It is not uncommon to encounter a barrage of exotic materials when perusing high-end support systems, but you'll find no such thing when you investigate the OConnor C12210001 Cine HD Tripod. Based on time-proven aluminum alloy metallurgy, there will be no surprises, and it requires no special accommodations. The single-stage design and die-cast spider ensure maximum rigidity for head and camera loads up to 309 lbs (140 kg), and the rotary stage clamps provide tool-free temperature-independent leg fixing. Concentrate on pressing production issues and forget about reinventing the wheel- your camera is safely suspended above the fray, and protected by the unbeatable OConnor 5-year parts and labor warranty.
  • Single stage design for maximum rigidity
  • Die-cast alloy spider/receiver top stage
  • Rotary stage clamps are temperature-independent
  • Dual leg spikes for high and low angles
• C1221-00015 Ground Spreader for Cine HD Tripod The OConnor C1221-00015 Ground Spreader is for use with the Cine HD tripod. It greatly enhances stability of the tripod with heavy loads while providing protection for delicate floor surfaces.

• Limited 1-Year Warranty Extendable to 2-Years with Product Registration

• Limited 1-Year Warranty Extendable to 2-Years with Product Registration

• Limited 1-Year Warranty, Extendable to 2 Years with Registration

• Limited 90-Day Warranty

Also Includes

• Limited 1-Year Warranty, Extendable to 2-Years with Product Registration

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• C12250001 120EX Standard Film Fluid Head (Black)

  Camera Plate Features	Sliding Balance Plate, Quick Release
  Camera Plate Type	120 mm Euro Plate, ARRI Dovetail Plate, OConnor Plate, Panavision Dovetail Plate

  Base Mount	Mitchell Flat Base

  Drag Control	Tilt: Continuous
