Product description

The DB500 from On-Stage is a single channel, passive direct box that transforms any high-impedance 1/4" source into a low-impedance signal, ready to be sent long distances to a mixing board or recording console. Housed in a rugged metal casing that will survive the rigors of the road, the unit features a high quality transformer, a ground lift switch, and does not require batteries or phantom power to function. The direct box is perfect for bass/acoustic guitar, keyboards and DJ equipment.
  • Single channel, passive direct box
  • Features a high quality transformer
  • Does not require batteries or phantom power
  • Ground lift switch
UPC: 659814883837 In the Box On-Stage DB500 - Direct Box (Passive)
  • One (1) Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the On-Stage DB500 - Direct Box in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    On-Stage DB500 Specs

    Type Passive
    Input Connections 1 x 1/4" TS phone
    Output Connectors 1 x XLR
    1 x 1/4" TS phone Pass Through
    Input Impedance 350kΩ
    Output Impedance 80Ω
    Controls Ground lift switch
    Power Passive - does not require batteries or phantom power
    Dimensions (WxDxH) 4.75 x 2.88 x 1.38" (121 x 73 x 35mm)
    Weight 5 lbs (2.3kg)
