Product description Enjoy enhanced multi-channel sound and THX certification with the Onkyo HT-S9800THX 7.1-Channel Network Home Theater System. This system produces up to 115W per channel at 6 Ohms and consists of a network-enabled A/V receiver, two front speakers, two surround speakers, two surround back speakers, a center speaker, and a 125W front-firing powered subwoofer. It can also accept optional height speakers for Dolby Atmos playback.
Built-in Bluetooth connectivity allows you to wirelessly pair with other Bluetooth-enabled audio sources such as computers, smartphones, and tablets for music playback. Onboard Wi-Fi and Ethernet connectivity give you the ability to stream music from Internet radio sources like Pandora and Deezer. You can also connect high-resolution audio sources to the receiver's rear-panel USB port.
The Onkyo HT-S9800THX has seven HDMI inputs for connecting digital audio and video sources. There is also a digital coaxial and two optical connections for interfacing additional audio sources. Built-in high-resolution audio support allows you to take advantage of high-resolution surround sound formats like DTS-HD and Dolby TrueHD. - THX Certified Select Reference Sound
- THX Integrated System certification is designed to guarantee theater-quality sound in an all-in-one package. Certified systems are well suited for smaller spaces where the screen-to-seat viewing distance is approximately 6 to 8'. All components within the system are tested to meet THX standards, delivering the same distortion-free sound volume you experience in a commercial theater.
- Dynamic Audio Amplification
- The high-current capability of Dynamic Audio Amplification is designed to drive 4-Ohm speaker loads, which test even strong amplifiers. This "muscle" means enhanced control, restoring energy to stereo and multichannel sound. In addition, VLSC is designed to eliminate pulse-noise for optimal playback of quality stereo sources.
- THX Integrated System Certified Speakers
- The included speaker system features solid MDF enclosures and A-OMF woofers (layered polyethylene naphthalate and flexible cotton weave). The surround speakers are equipped with A-OMF drivers to help ensure full-scale surround sound. The front-firing subwoofer fitted with a 12" cone outputs 125 watts of bass.
- Dolby Atmos and DTS:X
- Object-based soundtracks allow independently mixed sound to play through any speaker in your system, moving above and around you with enhanced realism. The HT-S9800THX reproduces 5.2.2-channel Dolby Atmos or DTS:X formats, with the included wall-mountable surround speakers reproducing overhead effects.
- Supports HDR10, HLG, Dolby Vision, BT.2020, 4K/60 Hz, and HDCP 2.2
- The six rear HDMI inputs and main out support pass-through of HDR10, Dolby Vision, HLG (Hybrid Log-Gamma), BT.2020, 4K/60 Hz video, and HDCP 2.2 for enhanced playback compatibility. The front HDMI input provides easy temporary connection for a video camera, while the sub out is well suited for projector connection.
- Wi-Fi, AirPlay, Spotify, & Bluetooth
- Selectable 5/2.4 GHz Wi-Fi helps ensure stable connectivity so you can enjoy smooth streaming over AirPlay, the Spotify app, and the local network. Bluetooth wireless technology also provides quick and simple wireless streaming from your choice of music application.
- Internet Radio and Streaming Services
- TIDAL, Deezer, Pandora, and TuneIn are onboard to make selecting from a range of music and radio programs using the Onkyo Controller app simple.
- Powered Zone 2
- Powered Zone 2 speaker outputs let you send amplified network, S/PDIF, and analog audio sources to a pair of speakers in another room. Control playback using the Onkyo Controller app.
- The Onkyo Controller App Supports Network Audio with FireConnect
- The Onkyo Controller app collects streaming services and local network audio so you can control playback, explore services, and distribute audio all over the home via FireConnect powered by Blackfire from one interface.
- FireConnect Wireless Multi-Room Audio, via Future Firmware Update
- FireConnect mirrors network audio and external analog sources connected to a master component, from streaming services to vinyl records, on optional FireConnect-compatible speakers in other rooms. Music selection, speaker grouping, and playback management across the home are built into the Onkyo Controller app for iOS and Android. FireConnect is scheduled to be made available following a future firmware update.
- Chromecast built-in, via Future Firmware Update
- Stream any music from your compatible smartphone, laptop, or computer to the HT-S9800THX. Control playback with Chromecast-enabled apps from your iPhone, iPad, Android phone or tablet, Mac or Windows laptop, or Chromebook. Chromecast built-in is scheduled to be made available following a future firmware update.
- DTS Play-Fi, via Future Firmware Update
- DTS Play-Fi is a wireless protocol that works with nearly any audio app on mobile devices and computers. Flick whatever's playing to the receiver, even different sources to different components at the same time.
- Additional Features
-
- Non-Phase-Shift circuitry
- Gaming, Rock, Sports, Action, and RPG DSP modes
- AccuEQ with AccuReflex
- VLSC for noiseless audio processing from front speakers
- Advanced Music Optimizer
- Phase-Matching Bass Boost for enhanced bass and midrange
- HDCP 2.2 copy protection
- HDMI support for ARC, CEC, LipSync, DVD-Audio, SACD, and Multichannel PCM
- InstaPrevue input source preview
- Analog to HDMI upconversion
- Powered and Line-Out Zone 2
- Streaming audio from USB memory
- IP control via LAN for home automation systems
- GUI OSD output
- DTS object-based audio reproduction and DTS Neural:X upmixing for legacy soundtracks
UPC: 889951000860 In the Box Onkyo HT-S9800THX 7.1-Channel Network Home Theater System Remote Control 2 x AAA Batteries Indoor FM Antenna AM Loop Antenna Speaker Setup Microphone Limited 2-Year Warranty More from Manufacturer Table of Contents
|
Upload User Manual
Have you got an user manual for the Onkyo HT-S9800THX 7.1-Channel Network Home Theater System in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersOnkyo HT-S9800THX Specs | | | Channels | 7.1 | | Power Output | 115 W per channel @ 6 Ohms, 1 kHz, 0.7 % THD, 2-channels driven, FTC | | Dynamic Power per Channel | 120 W (8 Ohms, front)
210 W (4 Ohms, front)
240 W (3 Ohms, front) | | THD & Noise | 0.08% (20 Hz to 20 kHz, half power) | | Damping Factor | 60 (front, 1 kHz, 8 Ohms) | | Input Sensitivity and Impedance | 200 mV / 47 kOhms (line) | | Output Level and Impedance | 200 mV / 2.2 kOhms (rec out) | | Frequency Response | 5 Hz to 100 kHz / +1 dB, -3 dB (direct mode) | | Tone Control | ±10 dB, 50 Hz (bass)
±10 dB, 20 kHz (treble) | | Signal-to-Noise Ratio | 106 dB (line, IHF-A)
80 dB (phono MM, IHF-A) | | Speaker Impedance | 6 to 16 Ohms | | Digital-to-Analog Converter (DAC) | AKM 192 kHz / 32-bit DACs | | Audio Decoder | Dolby Decoder: TrueHD, Dolby Surround Upmixing
DTS Decoder: DTS-HD Master Audio, DTS Neural:X | | Supported Formats | MP3, WMA, WAV, AIFF, AIF, AAC, M4A, MP4, 3GP, 3G2, FLAC, Apple Lossless, DSD 2.4/5.6 MHz, Dolby TrueHD (VR, MLP) | | | | Input Sensitivity/Output Level and Impedance | 1.0 Vp-p / 75 Ohms (component Y)
0.7 Vp-p / 75 Ohms (component PB / CB, PR / CR)
1.0 Vp-p / 75 Ohms (composite) | | Component Video Frequency Response | 5 Hz to 50 MHz / +0 dB, -3 dB | | | | Tuning Frequency Range | FM: 87.5 MHz to 107.9 MHz
AM: 530 kHz to 1710 kHz | | FM/AM Preset Memory | 40 stations | | | | Wi-Fi | Dual-band 5/2.4 GHz | | Bluetooth | Version: 4.1 + LE,
Profile: A2DP v1.2, AVRCP v1.3 | | Deep Color / x.v. Color Support | Yes | | HDMI CEC | Yes | | Audio Return Channel (ARC) | Yes | | Inputs | 7 x HDMI (1 front)
2 x component video
2 x composite video
1 x digital coaxial
2 x optical TOSLINK
7 x stereo RCA (1 phono)
1 x 1/8" (3.5 mm) aux in (front)
1 x USB | | Outputs | 2 x HDMI
1 x stereo RCA Zone 2
1 x 1/4" (6.35 mm) headphone (front)
2 x subwoofer | | Other Interfaces | 1 x Ethernet
1 x setup mic (front)
1 x AM antenna
1 x FM antenna | | Speaker Connectors | 9 x binding post pairs | | | | Type | Front, Center, Surround, Surround Back: 2-way, acoustic-suspension
Subwoofer: Acoustic-suspension, powered | | Drivers | Front, Center:
2x 5" (12 cm) cone woofers
1x 1" (2.5 cm) soft-dome tweeter
Surround, Surround Back:
1x 5.125" (13 cm) cone woofer
1x 1" (2.5 cm) soft-dome tweeter
Subwoofer:
1x 12" (30 cm) cone | | Maximum Input Power | 130 W per channel | | Rated Output Power | Subwoofer: 125 W (minimum continuous power, 6 ohms, 100 Hz, 1% THD, FTC) | | Frequency Response | Front, Center, Surround, Surround Back: 50 Hz to 45 kHz
Subwoofer: 20 Hz to 100 Hz | | Output Sound Pressure Level | Front, Center: 83 dB/W/m
Surround, Surround Back: 81 dB/W/m | | Nominal Impedance | Front, Center, Surround: 8 Ohms | | Input Sensitivity and Impedance | Subwoofer: 280 mV / 20 kOhms | | Cabinet Construction | Wood | | | | Power Consumption | Typical: 630 W
Standby: 0.1 W | | Power Requirements | 120 VAC, 60 Hz | | Dimensions (W x H x D) | Receiver: 17.125 x 6.8 x 13" (435 x 173.5 x 329 mm)
Front: 6.25 x 17.06 x 7.81" (158 x 433 x 199 mm)
Center: 17.06 x 6.25 x 7.81" (433 x 158 x 199 mm)
Surround, Surround Back: 7.875 x 10.81 x 6.625" (200 x 275 x 169 mm)
Subwoofer: 14.94 x 17.5 x 16.875" (380 x 444 x 429 mm) | | Weight | Receiver: 22 lb (10 kg)
Front, Center: 11.7 lb (5.3 kg)
Surround, Surround Back: 7.7 lb (3.5 kg)
Subwoofer: 34.2 lb (15.5 kg) | | | | Package Weight | 140.0 lb | | Box Dimensions (LxWxH) | 44.0 x 29.0 x 20.0" |
