Product description Buying Guide to Projectors Read More zscwfufbesrvdtawsddfcbcusavuav Enjoy UHD 4K content with HDR support with the Optoma UHD50 XPR UHD DLP Home Theater Projector. Its 2400 lumens of brightness overcome ambient light in many installations, while its 500,000:1 dynamic contrast ratio helps enhance detail in dark areas of the image. UHD 3840 x 2160 resolution via XPR technology helps ensure that text and images are clear. HDR10 compatibility ensures vibrant color reproduction from a compatible source device and content.
The UHD50 has one VGA and two HDMI inputs to support a variety of sources. Both HDMI inputs are MHL-compatible for connecting mobile devices, such as your smartphone or tablet, and the projector has a USB power output to help conserve your device's battery life. Its analog audio input and output allow you to either use the built-in 5W speakers or output your audio to an external system with the optical audio output, a digital audio connection to your receiver or soundbar. The projector is controllable via Ethernet, RS-232, or the included IR remote control. - XPR technology combines image processing with the ability of the DMD's mirrors to shift at the microsecond level to allow each mirror to project two pixels per frame, creating a UHD 4K image from an otherwise non-UHD chip.
- Equipped with HDR10 and DCI-P3 wide color gamut support for bright whites, deep blacks, and vivid color
- Dynamic Black delivers a 500,000:1 dynamic contrast ratio for enhanced black levels
- HDMI 2.0 and HDCP 2.2 offer UHD video bandwidth and device compatibility
- Vertical lens shift and 1.3x zoom provide flexible installation
- Two 5W speakers and an optical output to your A/V receiver or soundbar
UPC: 796435813000 In the Box Optoma Technology UHD50 XPR UHD DLP Home Theater Projector Remote Control with Batteries HDMI Cable Lens Cap AC Power Cord Limited 1-Year Warranty Limited 90-Day Warranty More info from Optoma Technology zscwfufbesrvdtawsddfcbcusavuav Table of Contents
|
Upload User Manual
Have you got an user manual for the Optoma Technology UHD50 XPR UHD DLP Home Theater Projector in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersOptoma Technology UHD50 Specs | | | Display System | 1x 0.66" (1.7 cm) DMD DLP | | Supported HD Resolution | UHD 3840 x 2160 at 60 Hz | | Maximum Resolution | Up to DCI 4K 4096 x 2160 at 60 Hz | | Maximum Brightness | 2400 ANSI lumens | | Aspect Ratio | Native: 16:9
Supported: 4:3, LBX | | Dynamic Contrast Ratio | 500,000:1 | | HDR Support | HDR10 | | Color Gamut Coverage | Rec. 2020, Rec. 709, DCI-P3 | | Color Depth | 3840 x 2160 @ 30 Hz YUV 4:4:4 (8-bit, 10-bit, 12-bit); YUV 4:2:2 (8-bit, 10-bit, 12-bit); YUV 4:2:0 (8-bit, 10-bit, 12-bit)
3840 x 2160 @ 60 Hz YUV 4:4:4 (8-bit), YUV 4:2:2 (8-bit), YUV 4:2:0 (8-bit, 10-bit, 12-bit) | | Color Wheel | Six-segment RGBRGB | | Uniformity | 80% | | Scan Rate | Vertical: 24 to 120 Hz
Horizontal: 31 to 135 kHz | | | | Lens | F=2.5 to 3.26, f=20.91 to 32.62mm | | Focus | Manual | | Zoom | Optical: 1.3x
Digital: 0.8 to 2x | | Throw Ratio | 1.21 to 1.59:1, ±5% tolerance | | Projection Distance | 2.9 to 34.89' (0.88 to 10.63 m) | | Image Size | 34.1 to 302.4" (86.6 to 768.1 cm)
34.1 to 140" (86.6 to 355.6 cm) optimal | | Offset | 100% | | | | Keystone Correction | Yes | | Projection Method | Front, rear, ceiling mount, tabletop | | Security | Cable lock slot, password protection | | Speaker | 2 x 5 W | | | | Inputs | 2 x HDMI with MHL
1 x 15-pin VGA
1 x 1/8" (3.5 mm) audio | | Outputs | 1 x 1/8" (3.5 mm) audio
1 x optical TOSLINK | | Other Connectors | 1 x USB Type-A (service)
1 x USB Type-A power out
1 x Ethernet LAN
1 x RS-232C control in
1 x 12 V trigger out | | HDMI Version | 2.0 | | HDCP Version | 2.2 | | Mobile High-Definition Link (MHL) | 2.1 | | | | Lamp Life | Bright Mode: 4000 hours
ECO Mode: 10,000 hours
Dynamic Mode: 15,000 hours | | Fan Noise | Bright Mode: 28 dB
Eco Mode: 25 dB | | Power Requirements | 100 to 240 VAC, 50 to 60 Hz (auto-switching) | | Power Consumption | Bright Mode, Typical: 317 W
Bright Mode, Max: 348 W
Eco+ Mode, Typical: 259 W
Eco+ Mode, Max: 285 W | | Operating Conditions | 41 to 104°F (5 to 40°C), 85% max humidity | | Maximum Altitude | 10,000' (3048 m) @ 73°F (23°C) | | Dimensions (W x H x D) | 15.4 x 5.1 x 11.1" (39.1 x 13 x 28.2 cm) | | Weight | 11.75 lb (5.33 kg) | | | | Package Weight | 16.5 lb | | Box Dimensions (LxWxH) | 20.5 x 15.0 x 8.1" |
