User Manual for Optoma Technology UHD51A HDR XPR UHD DLP Home Theater Projector Click to enlarge the picture
Contents of the user manual for the Optoma Technology UHD51A HDR XPR UHD
- Product category: Home Theater Projectors Optoma Technology
- Brand: Optoma Technology
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Optoma Technology Home Theater Projectors
 |
User manual for the Optoma Technology UHD51A HDR XPR UHD contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Optoma Technology product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Optoma Technology user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Optoma Technology product will considerably shorten its lifespan!
|
Product description Buying Guide to Projectors Read More Enjoy your video games and multimedia content with Amazon Alexa control with the Optoma UHD51A HDR XPR UHD DLP Home Theater Projector. It uses XPR technology to produce UHD 4K on-screen images with compatible content and features HDR10 compatibility to produce a wide color gamut. It outputs up to 2400 ANSI lumens of brightness and has a 500,000:1 dynamic contrast ratio to help produce details even in dark areas of the image.
The projector has two HDMI inputs for connecting your digital HD devices such as a gaming console, Blu-ray player, or cable/satellite box. Its two built-in 5W speakers eliminate the need for external speakers if none are convenient. The included wireless USB adapter allows you to control the projector with just your voice through your Amazon Alexa- or Google Assistant-enabled devices; for more traditional control options, you can use the included IR remote. - XPR Technology Projects UHD Resolution
- XPR technology combines image processing with the ability of the DMD's mirrors to shift at the microsecond level to allow each mirror to project two pixels per frame, creating a UHD 4K image from an otherwise non-UHD chip.
- Ready for Alexa Smart Home and Custom Skills
- Alexa compatibility allows you to power the projector on and off, adjust the volume, change the input source, control playback via the onboard media player, change the display mode, HDR picture modes, and the PureMotion setting, with your Alexa-enabled equipment.
- Compatible with the Google Assistant
- Google Voice Action compatibility provides projector control via the Google Assistant. Supported control functions include power on/off, volume level, input selection, USB media player playback, and more.
- Additional Features
-
- HDR10 support helps provide brighter whites, deeper black levels, and vivid colors
- Dynamic Black helps produce a 500,000:1 dynamic contrast ratio for enhanced black levels
- HDMI 2.0 with HDCP 2.2 ensures compatibility with UHD 4K video sources
- Vertical lens shift and 1.3x zoom simplify installation
- Normal, Bright, Detail, and Film picture modes
- Upscales WXGA, 720p, 1080p, WUXGA, and 1440p resolutions and frame rates to UHD 4K, 60 Hz
- UltraDetail technology helps enhance image quality with augmented depth and clarity
- Native 16:9 aspect ratio, compatible with 4:3 and LBX
- Full-function remote control
- Cast videos, images, and music from compatible Android, iOS, Windows, and Mac OS X devices
- Integrated web browser provides access to popular websites for video streaming
- Mirror Android, Windows, and Mac OS X devices
- Supports autoplay of PDF and PowerPoint files in 3, 5, 10, 15, and 20-second intervals
- Audio pass-through from HDMI to 1/8" output
UPC: 796435813086 In the Box Optoma Technology UHD51A HDR XPR UHD DLP Home Theater Projector Remote Control with Batteries Lens Cap HDMI Cable Wireless USB Adapter for Alexa or Screen Mirroring Power Cord Limited 2-Year Warranty Limited 90-Day Warranty More info from Optoma Technology Table of Contents
|
Upload User Manual
Have you got an user manual for the Optoma Technology UHD51A HDR XPR UHD DLP Home Theater Projector in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersOptoma Technology UHD51A Specs | | | Projection System | DMD DLP | | Chip Size | 0.47" / 1.19 cm | | On-Screen Graphics | Up to UHD (3840 x 2160) via XPR | | Maximum Resolution Supported | DCI 4K (4096 x 2160) @ 60 Hz | | Native Aspect Ratio | 16:9 | | Color Depth | 3840 x 2160 @ 30 Hz: YUV 4:4:4 (8-bit, 10-bit, 12-bit), YUV 4:2:2 (8-bit, 10-bit, 12-bit), YUV 4:2:0 (8-bit, 10-bit, 12-bit)
3840 x 2160 @ 60 Hz: YUV 4:4:4 (8-bit), YUV 4:2:2 (8-bit), YUV 4:2:0 (8-bit, 10-bit, 12-bit) | | HDR Support | HDR10 | | Brightness | 2400 ANSI lumens | | Uniformity | 80% | | Dynamic Contrast Ratio | Up to 500,000:1 with Dynamic Black | | Color Space | Rec. 709 for non-HDR content
DCI-P3
Rec.2020 for HDR | | Scan Rate | Horizontal: 31 to 135 kHz
Vertical: 24 to 120 Hz | | Color Wheel | 6-segment (RGBRGB) | | Projection Method | Front, rear, ceiling mount, tabletop | | | | Focus | Manual | | F-Number (f) | 2.5 to 32.6 | | Focal Length | 20.91 to 32.62mm | | Throw Ratio | 1.21 to 1.59:1 with ±5% tolerance | | Supported Image Size | Optimal Clarity: 34.1 to 140" / 86.6 to 355.6 cm
Maximum: 302.4" / 768.1 cm | | Throw Distance | 2.9 to 34.89' / 0.9 to 10.6 m | | Zoom Ratio | Optical: 1.3x
Digital: 0.8 to 2x | | Offset | 100% | | Lens Shift | 15% vertical with ±5% tolerance | | | | Inputs | 2 x HDMI with MHL
1 x 15-pin VGA
1 x 1/8" / 3.5 mm audio | | Outputs | 1 x optical TOSLINK
1 x 1/8" / 3.5 mm audio | | Other Connectors | 1 x USB Type-A (Alexa/Wi-Fi adapter only)
1 x USB Type-A (media player only)
1 x USB Type-A (wireless display only)
1 x USB Type-A (version 2.0, service only)
1 x Ethernet LAN
1 x 9-pin RS-232 control in
1 x 1/8" / 3.5 mm 12 VDC trigger out | | HDMI Version | 2.0 | | HDCP Version | 2.2 | | MHL | Version: 2.1 | | USB Formats | Video: MKV, MP4, M4V, AVI, H.264, HEVC, MOV, TS
Audio: MP3, AAC, WAV, FLAC 16/24-bit
Images: JPEG, BMP, GIF
Documents: Word, Excel, PowerPoint | | | | Lamp Life | High Brightness Mode: 4000 hours
Medium Brightness Mode: 10,000 hours
Low Brightness Mode: 15,000 hours | | 3D Compatibility | Yes | | Supported 3D Formats | Frame Packing: 1080p, 24 Hz; 720p, 50/60 Hz
Side-by-Side: 1080i, 50/60 Hz; 720p, 50/60 Hz
Top/Bottom: 1080p, 24 Hz; 720p, 50/60 Hz | | Supported Languages | Not specified by manufacturer | | Built-in Speaker | 2 x 5 W | | Fan Noise | High Brightness: 28 dB
Low Brightness: 25 dB | | Security | Cable lock slot, OSD password | | Operating Conditions | Temperature: 41 to 104°F / 5 to 40°C
Maximum Humidity: 85% | | Power Requirements | 100 to 240 VAC, 50/60 Hz, auto-switching | | Power Consumption | Typical, High Brightness Mode: 317 W
Maximum, High Brightness Mode: 348 W
Typical, Low Brightness Mode: 259 W
Maximum, Low Brightness Mode: 285 W | | Dimensions (W x H x D) | 15.1 x 5.1 x 11.1 / 38.4 x 13 x 28.2 cm | | Weight | 11.75 lb / 5.3 kg | | | | Package Weight | 15.5 lb | | Box Dimensions (LxWxH) | 20.5 x 15.0 x 8.0" |
