Product description The Osprey 260e is a single-channel analog capture card offering Composite BNC, Component 3-BNC, and S-Video mini-DIN selectable inputs, along with balanced XLR or unbalanced RCA stereo audio, all via a breakout cable. The S-Video input comes on BNC connectors and is converted via an included BNC to mini-DIN adapter. Two or more cards can be deployed in a single PC chassis for maximum versatility.
This 260e card comes with Osprey's SimulStream driver enhancement software, which allows each input to produce multiple parallel output streams with completely independent settings for color space, cropping, scaling, closed caption, and overlays, allowing for simultaneous delivery to multiple applications. - Driver Support
-
- Microsoft DirectShow drivers are available for compatibility with most software
- Open source Linux V4L drivers available
- Microsoft Windows lets you create custom applications
- Driver Based Pre-Processing (Windows DirectShow Only)
-
- Closed-caption extraction/rendering
- Logo/bitmap overlay
- Scaling, cropping, de-interlacing, and inverse telecine
UPC: 850189006047 In the Box Osprey 260e Video Capture Card with SimulStream BNC to Mini-DIN Adapter Breakout Cable Low Profile Bracket Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Osprey 260e Video Capture Card with SimulStream in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersOsprey Osprey 260e Specs | Format | 1 x PCIe
Slots: x1, x4, x8, or x16
PCIe 1.1 | | Breakout Cable Connector | 15-pin connector (breakout cable included) | | Video Input | 1 x Composite on BNC
1 x Component on 3 BNCs
1 x Y/C on 2 BNCs (BNC to mini-DIN adapter) | | Video Modes | NTSC/PAL
720 x 480 29.97, 30/i (NTSC)
852 x 480, 29.97, 30/i (NTSC Wide Screen)
720 x 576 25/i (PAL)
Wide Screen Signaling (WSS) | | Audio Input | 1 x Balanced stereo via 2 XLR connectors
1 x Unbalanced stereo via 2 RCA connectors | | Audio Output | Unbalanced stereo line (3.5 mm) | | Power Consumption | 3.58 W | | Operating Temperature | 32 to 104°F (0 to 40°C) | | Storage Temperature | -40 to 167°F (-40 to 75°C) | | Operating Relative Humidity | 5 to 80% (non-condensing) | | Storage Relative Humidity | 95% RH (non-condensing); gradient 30% per hour | | Operating Altitude | 0 to 10,000 ft (0 to 3,048 m) | | Storage Altitude | 0 to 50,000 ft (0 to 15,240 m) | | Dimensions | L x H: 5 x 2.7" (12.7 x 6.7 cm)
Low profile/half length | | Weight | 2.3 oz (67 g) | | | | Package Weight | 0.9 lb | | Box Dimensions (LxWxH) | 9.2 x 5.4 x 2.2" |
