Product description ViewCast's Osprey A/V Option for 450e/460e is an expansion for the Osprey 450e/460e cards to allow access to component or Y/C (S-Video) video inputs as well as balanced stereo audio inputs on the board. This option includes two connector cables and an expansion circuit board with a bracket to expose the additional audio/video inputs. No audio or video input cables are provided with this option.
Note: This part requires Osprey 450e Balanced Audio Panel and/or Osprey 450e Component Video Panel to access the input connectors for balanced audio, component and Y/C video inputs. Only one Osprey 450e/460e A/V Option is required per Osprey 450e or 460e card. UPC: 850189006306 In the Box Osprey A/V Option for 450e/460e 2 x Connector Cables Expansion Circuit Board Table of Contents
|
Upload User Manual
Have you got an user manual for the Osprey A V Option for 450e 460e in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersOsprey 95-00459 Specs | | | Package Weight | 0.45 lb | | Box Dimensions (LxWxH) | 9.1 x 5.5 x 2.2" |
