User Manual for OWC Other World Computing Mercury Elite Pro Dual mini 4TB 2-Bay USB 3.1 Type-C RAID Array Click to enlarge the picture
Contents of the user manual for the OWC Other World Computing Mercury Elite
- Product category: Hard Drive Arrays OWC / Other World Computing
- Brand: OWC / Other World Computing
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for OWC / Other World Computing Hard Drive Arrays
 |
User manual for the OWC Other World Computing Mercury Elite contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any OWC / Other World Computing product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official OWC / Other World Computing user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a OWC / Other World Computing product will considerably shorten its lifespan!
|
Product description RAID Arrays for Photography and Pro Video Read More With a USB 3.1 Type-C interface, the 4TB Mercury Elite Pro Dual mini 4TB 2-Bay RAID Array from OWC / Other World Computing can transfer large files quickly and efficiently. In addition to enhanced data transfer rates, this external hard drive supports both RAID 0 and RAID 1 configuration modes allowing you to configure the two internal drives for speed or redundancy. OWC has preconfigured the two 2TB hard drives in a RAID 0 array. Both drives reside inside a rugged aluminum chassis with a fanless design to keep them cool and protected even when on the go. - RAID for Redundancy, RAID for Performance
- The Mercury Elite Pro Dual mini allows you to choose the configuration that suits your needs with user selectable modes RAID 0 and RAID 1. In RAID 0, the drives have an increased data transfer speed, or you can select RAID 1 for greater data redundancy from mirrored disks.
- Intuitive Design
- A rugged aluminum chassis designed for near silent fanless, cooling, keeps your drives protected, cool and quiet everywhere you go. The slimline, side-by-side configuration means Mercury Elite Pro Dual mini fits easily in your laptop or gear bag. And because it's fully bus-powered, Mercury Elite Pro Dual mini is a suitable solution for your portable creative workflow.
UPC: 812437023893 In the Box OWC / Other World Computing Mercury Elite Pro Dual mini 4TB 2-Bay USB 3.1 Type-C RAID Array (2 x 2TB) USB Type-C to USB Type-C Cable External Power Supply Utility Software Bundle Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the OWC Other World Computing Mercury Elite Pro Dual mini 4TB 2-Bay USB 3.1 Type-C RAID Array in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersOWC / Other World Computing MEMDC2H5T4.0 Specs | Software Requirements | OS
OS X 10.7 or later
Windows 7 or later
Driver
Driver not required for OS X
Driver not required for Windows | | Hardware Requirements | Minimum
Mac or PC with a USB 3.0 port (Standard-A or Type-C)
Recommended (Best Performance)
Mac or PC with a USB 3.1 Type-C port | | Bootability | OS X 10.7 or later | | Interface (Chipset) | 1 x USB 3.1 / SATA RAID Controller (ASMedia ASM1352R) | | UASP Support | Yes | | Standard Mechanism | 2 x 2 TB
5400 rpm | | RAID Modes Supported | Hardware
RAID 0, 1, SPAN, and Independent drive mode | | Initial Configuration | RAID 0
Included Drive Guide software will format the drive for either OS X or Windows | | Power | Power Supply
External UL-listed universal auto-switching
AC input: 100 ~ 240 V, 50/60 Hz
DC output: 12 V @ 3 A | | Temperature | Operating Temperature: 32 to 107°F / 0 to 42°C
Non-Operating Temperature: -40 to 185°F / -40 to 85°C | | Dimensions | 1.1 x 6.1 x 5.7" / 28 x 155 x 144 mm | | Weight | 1.3 lb / 0.60 kg | | | | Package Weight | 3.15 lb | | Box Dimensions (LxWxH) | 10.2 x 8.2 x 3.2" |
