User Manual for OWI Inc. TRP470 70V Trumpet Speaker Click to enlarge the picture
Contents of the user manual for the OWI Inc. TRP470 70V Trumpet Speaker
- Product category: Installed Speakers OWI Inc.
- Brand: OWI Inc.
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for OWI Inc. Installed Speakers
|
User manual for the OWI Inc. TRP470 70V Trumpet Speaker contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any OWI Inc. product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official OWI Inc. user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a OWI Inc. product will considerably shorten its lifespan!
|
Product description The paintable white-colored TRP470 70V Trumpet Speaker from OWI Inc. has a 4” full-range driver. This 4Ω speaker features a 1.5, 3.5, 7.5, 15, and 30W power selector and has a 60’ throw, and 120° horizontal by 90° vertical dispersion. It is weatherized with a paintable white-colored ABS plastic enclosure and features an aluminum grill. This speaker comes with a C bracket for wall, ceiling, or pole mounting. - 70V & 4Ω combination system
- 1.5, 3.5, 7.5, 15, 30W power selector
- 140 Hz to 20 kHz (music), 250 Hz to 3 kHz (paging)
- Dispersion (H x V): 120 x 90°
- C mounting bracket for pole, ceiling, or wall mounting
UPC: 092087917487 In the Box OWI Inc. TRP470 70V Trumpet Speaker (4Ω, White) C Bracket Terminal Cover Plate Security Cable Limited 5-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the OWI Inc. TRP470 70V Trumpet Speaker in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersOWI Inc. TRP470 Specs | Material | Enclosure: ABS plastic
Woofer: Coated paper
Grill: Aluminum | | Switch | Selectable: 70 V & 4 Ω combination | | Transformer Taps | 70 V: 1.5, 3.5, 7, 15, 30 W (selector knob) | | Sensitivity | 90 dB (1 W/1 m) | | Power | Handling: 4 Ω
Maximum Power: 80 W
Nominal Power: 40 W | | Frequency Response | Music: 140 Hz to 20 kHz
Speech: 250 Hz to 3 kHz | | Dispersion | H x V: 120 x 90° | | Throw Distance | 60.00' (18.29 m) | | Operating Temperature | 14 to 176°F (-10 to 80°C) | | Size | Woofer: 4.0" (101.6 mm) | | Dimensions (L x W x H) | 10.00 x 9.80 x 5.90" (254.00 x 248.92 x 149.86 mm) | | Weight | 6.80 lb (3.08 kg) | | | | Package Weight | 7.9 lb | | Box Dimensions (LxWxH) | 12.2 x 11.6 x 8.0" |
