Product description Visualize electrical waveforms to test and debug circuits with the HDS-N Series 2-Channel Handheld Digital Storage Oscilloscope from OWON Technology. This 2-in-1 oscilloscope and multimeter offers a bandwidth of 20 MHz, sample rates of 100 MS/sec, and record lengths of 6000 points. The signals are plotted on a 3.7" TFT display. - Main Features
-
- Auto-scale function
- FFT function
- 20 automatic group measurement choices
- Supports USB data transmission
- Rechargeable lithium-ion battery, six-hour runtime
- Waveform record and replay
- Multimeter supports SCPI
- Applications
-
- Design and manufacture
- Education and training
- Automobile maintenance and testing
In the Box OWON Technology HDS-N Series 2-Channel Handheld Digital Storage Oscilloscope (20 MHz) Power Cord CD Rom USB Cable 2 x Probe Probe Adjust Tool 2 x Multimeter Lead Power Adapter 5V, 1 kHz Output Terminal Capacitance Ext Module Metal Case Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the OWON Technology HDS-N Series 2-Channel Handheld Digital Storage Oscilloscope in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersOWON Technology HDS1022M-N Specs | | | Full Scale Level | 3 3/4 digits (max 4000-count) | | Input Impedance | 10 MOhms | | Diode Current Measurement | 0 to 1.5 V | | On/Off Test | < 50 (
