User Manual for PAG PL150T 150Wh 14.8V 8Ah V-Mount Battery with Run-Time and Capacity Display Click to enlarge the picture
Contents of the user manual for the PAG PL150T 150Wh 14.8V 8Ah V-Mount
- Product category: On Camera Batteries PAG
- Brand: PAG
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for PAG On Camera Batteries
|
User manual for the PAG PL150T 150Wh 14.8V 8Ah V-Mount contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any PAG product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official PAG user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a PAG product will considerably shorten its lifespan!
|
Product description The PL150T 150Wh 14.8V/8Ah V-Mount Battery from PAG uses intelligent linking technology, making it suitable for powering any broadcast or digital cinema camera, and multiple accessories. Up to 12A can be drawn when batteries are linked. You can also double the capacity to 300Wh by linking 2 batteries.The battery features a V-mount format and can be charged using any Li-ion charger. It can also be linked with PL96 batteries (V-Mount) for charge or discharge for added convenience.The PL150T battery uses a numeric display, which shows a prediction of remaining camera run-time, on-load in hours and minutes, and capacity as percentage. - Link with PL96 batteries for charge or discharge
- Up to 12A when the batteries are linked
- Hot-swap batteries for continuous power
- Numeric Run-Time and Capacity display
- Auto-communication with multiple camera data systems for in-viewfinder capacity display
- Intelligent battery that manages its own charge and discharge safely
- Heavy-duty pin-type contacts for high-load applications
- Tested to UN standards by an independent authority
- Fail-safe electronic protection system, conformally coated
- Two PL150 batteries can be transported by air in your hand-luggage
- Future-proof with externally programmable firmware
- High-impact polycarbonate injection moldings designed to protect the cells from impact damage
- PAGlink latching mechanism can be replaced in the event of damage, without opening the sealed battery case
- Battery firmware can be updated in the field by the user via the battery contacts
In the Box PAG PL150T 150Wh 14.8V/8Ah V-Mount Battery with Run-Time and Capacity Display Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the PAG PL150T 150Wh 14.8V 8Ah V-Mount Battery with Run-Time and Capacity Display in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersPAG PL150T Specs | Capacity | 10 Ah, 150 Wh | | Battery Cells | Sealed lithium-ion rechargeable cells | | Voltage | 14.8V nominal
12 cells connected in series/parallel
Each cell has a nominal voltage of 3.7 V | | Output Current | 8 A (12 A for two or more linked batteries) | | Charge Voltage | 16.8 V | | Construction | Polycarbonate injection moldings | | Integrated Protection System | 3 Over-current
2 Over-voltage
2 Under-voltage
3 Thermal (including non-resetting thermal fuse) | | Temperature Range | Discharging: -4 to 122°F (-20 to 50°C), Optimum: 50 to 104°F (10 to 40°C)
Charging: 32 to 113°F (0 to 45°C), Optimum: 50 to 104°F (10 to 40°C)
Storage: 14 to 104°F (-10 to 40°C), Optimum: 32 to 68°F (0 to 20°C) | | Dimensions (H x W x D) | 5.2 x 3.3 x 1.9" (133 x 84 x 50 mm) | | Weight | 1.7 lb (0.775 kg) | | | | Box Dimensions (LxWxH) | 6.0 x 6.0 x 6.0" |
