Product description

• Panasonic AG-CX350 - First Look

Dual-System Camera
• You can select from 59.94 or 50 Hz as the signal system for the camera. This is useful as it allows you to shoot in different countries with minimal concerns over flickering lights.

Sensor
• The 1" MOS sensor features 15MP resolution, easily supporting UHD with its native resolution of 5170 x 2908.

Signal Processing
• Camera features:
  • Eight user-selectable gamma modes—HD, SD, Filmlike 1, Filmlike 2, Filmlike 3, Film-Rec, Video-Rec, and HLG for HDR recording.
  • You can choose to output HDR over the 3G-SDI or HDMI output either individually or simultaneously.
  • Provides a 16-axis color control of your image with three skin-tone control so you can isolate and adjust your colors precisely and protect your skin tones.

Lens
• The 20x optical zoom lens has a 35mm focal length equivalent to 24.5 to 490mm. 24.5 is an extremely wide angle for a UHD camcorder. It features 5-Axis Hybrid Image Stabilization in both 4K and HD, which can be useful when hand-holding the camcorder. The lens also features individual lens control rings for zoom, focus, and iris. This enables manual control of your lens (in addition to servo), similar to the control you get on full-sized shoulder-mounted cameras.

  Additional features of the lens include:
  • Intelligent autofocus with subject tracking.
  • Custom AF function: The autofocus speed can be set in 7 steps, the sensitivity can be set in 10 steps, and the AF selection area can be adjusted.
  • The lens is controllable from third-party wired devices and also from iOS and Android tablets.

Frame Rate
• The camera records at standard speeds—23.98, 25, 29.97, 50, 59.94. It also records at variable frame rates in both UHD and HD; from 1 to 60 fps in UHD and 1 to 120 fps in HD.

Recording Media
• The AG-CX350 features SD card slots, providing you with a wide choice of media to choose from, all sold separately.

  If you already have P2 cards, the camcorder is compatible with them with a caveat. The CX350 can record onto a microP2 card as an SD card, but please be aware that:
  • microP2 card A series 64GB card (AJ-P2M064A) when used as an SD card is recognized as Speed Class 10.
  • microP2 card A series 32GB card (AJ-P2M32A) is recognized as Speed Class 4 for AVCHD only.
  • microP2 card B series (AJ-P2M064B) is recognized as Speed Class V90 for all formats.

Dual Slots
• The dual SD media slots permit you to choose from the following recording schemes:
  • Relay recording: As one card fills up, the recording automatically switches to the second card so you don't have to stop recording.
  • Simultaneous recording: Both cards record the same material at the same time.
  • Background recording: Starts both cards recording simultaneously, but the run/stop button will pause the recording on one card.

Networking
• The camera features an Ethernet port that allows you to connect it directly to a LAN (bypassing the need for a computer) and transfer your files to an FTP server with a global IP address. You can also use this port for wired streaming.

Wireless Networking
• The camera uses standard streaming protocols. Using an available AJ-WM30 USB dongle, you can connect the camera to a Wi-Fi network and transfer files to an FTP server. Available third-party dongles will allow 4G/LTE connectivity.

Enhanced Network Connectivity
• The CX350 has preinstalled support of NDI, which provides:
  • Automatic discovery and ease of use
  • Built-in support for NDI via NDI|HX
  • Ultra-low latency
  • Camera control and tally

Live Streaming
• High-image quality FHD streaming without a PC or an encoder unit. During streaming, UHD/FHD video can be recorded to SD cards in the camera body.

Wireless Control from Smartphone/Tablet
• The CX ROP app for iOS/Android allows the following:
  • Camera recorder information display/control user's button
  • Camera Rec start/stop
  • Camera recorder output signal select (camera/color bars)
  • Zoom
  • Focus
  • Knee
  • Shutter
  • Gain
  • White balance
  • Master pedestal
  • Iris
  • Paint (painting gain, painting black)
  • Timecode/user's bit setting
  • User SW 1~9

Simultaneous SDI and HDMI Out
• The CX350 supports simultaneous output of HDMI and SDI, with HDMI up to UHD and SDI to FHD video, both at 4:2:2 10-bit

Audio
• Supports two channels of audio recording from the built-in stereo microphone or two XLR audio inputs (48V phantom power, Mic, and Line are switchable). In MOV mode the camcorder supports 24-bit linear PCM audio. Other professional features include the OSD level meter and 1 kHz test tone output when the color bar is displayed in 59.94 Hz (when 50 Hz is selected test tone is 997 Hz).

Multicamera Recording
• The TC In/Out terminal (BNC) allows synchronization for multicamera shooting.

Upload User Manual

Please enter here the link to the user manual of this product: User manual for Panasonic AG-CX350 4K Camcorder can be downloaded below, so the upload option is not active. OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0% User manual for Panasonic AG-CX350 4K Camcorder can be downloaded below, so the upload option is not active.

Download User Manual

Download PDF User Manual - Panasonic AG-CX350 4K Camcorder (PDF file, 0 MB)

Technical parameters

Panasonic AG-CX350 Specs

Shutter Speed	1/2 to 1/10,000 sec When in Slow Shutter Mode
Shutter Angle	3 to 360 Rating 100% users recommend this product to others. And what about you? This product has already been rated by 05 owners. Add your rating and experience with the product. Discussion Ask our technicians if you have a problem with your settings, or if anything is unclear in the user manual you have downloaded. You can make use of our moderated discussion. The discussion is public and helps other users of our website who may be encountering similar problems. The discussion is empty - enter the first post Post a new topic / query / comment: Items marked with * are required. Your name *: E-mail : Subject *: Message *: Your email address will not be displayed. Do not forget to fill it in if you want to receive a reply to your enquiry/contribution. Processing of personal data in accordance with GDPR
