Product description For a wide range of high-resolution and professional options when mobile or in the studio, use the Panasonic AG-UX180 4K Professional Camcorder for recording up to 4K24p 4096 x 2160 video and 8-mode gamma.
The AG-UX180 features a large, 1.0-type MOS sensor that creates a dramatic bokeh with its wide-angle lens, and its focal length with 20x optical zoom ranges from 24 to 480mm. The camera's 5-axis Hybrid Image Stabilizer provides anti-shake correction for smooth movement, and the 3-ring lens design allows for precision iris/focus/zoom manual control. The shutter system functions in three modes—System, Slow, and Syncro Scan—which allow shutter speeds from 1/60 to 1/8000 sec. Four-step, built-in ND filters and variable gain settings allow for greater control over brightness and shutter.
Recording functions include DCI and UHD 4K/FHD/HD/SD resolutions, MOV, MP4, and AVCHD formats with MPEG-4 and H.264 compression, slow-motion video up to 120 fps, Pre Rec pre-recording function, interval recording for time-lapse, freeze frame, timestamp and timecode, JPEG still recording up to 8.8MP 4096 x 2160 resolution, and 16-bit/48 kHz LPCM or Dolby stereo audio. Two SD slots record onto SDHC/SDXC media, and UHS-I format is supported. Rollover recording is also supported, which allows recording to continue by automatically switching to the second slot when the first card is full. Recording to external media is also supported via a USB 3.0 output. The camera supports dual XLR inputs, HDMI/3G-SDI/SD-SDI/AV audio and video output, 3.5mm stereo headphone output, and BNC timecode output.
The camera's auto-assist operations feature a variety of tasks such as high-speed 4K autofocus, automatic white balance, one-touch AF, manual focus assist, and focus preset transition, as well as peaking, auto iris, and brightness display functions. Image adjustment presets include 16-axis color correction, skin and master detail, and six preset scene files with slots for custom scene files. Use the 3.5-type HD display or the .39-type OLED viewfinder to preview your video and view your settings.
The AG-UX180 also supports infrared shooting with a separately available IR light, and it supports wireless transmission with a separately available wireless module. Accessory mounting options include a cold shoe mount on top. A 5900mAh AG-VBR59 battery, a battery charger, a microphone holder, an AC adapter, an eye cup, a lens hood with lens cover, and an INPUT terminal cap are included. - 4/3-type MOS sensor for dramatic bokeh effects and DCI 4K 4096 x 2160 resolution.
- Eight selectable gamma modes, including Cine-Like gamma.
- Variable frame rate HD recording and slow mode up to 120 fps.
- Includes a built-in 24 to 480mm lens with 20x optical zoom and intelligent full-auto functions.
- High-quality 4K 8-bit 4:2:0 images can be output via the HDMI terminal.
- Microdrive focus unit provides a high-speed, high-precision intelligent autofocus.
- Advanced Optical Image Stabilizer (OIS) expands correction area with ball OIS system.
- The 5-axis Hybrid Image Stabilizer effects handshake correction in various directions (does not work in DCI/UHD 4K mode).
- Dual Codec Recording allows images to be simultaneously recorded into two different formats—main UHD/FHD and Sub FHD (UHD 60/50p mode is not supported).
- Two SDHC/SDXC memory card slots boost recording reliability with background/relay/simultaneous recording and SD memory card copy.
- The three manual focus/iris/zoom rings and other controls are specially designed to satisfy professional users.
- Equipped with professional interfaces such as HDMI, AV, and 3G-SDI out, XLR-in, and TC preset in/out.
- Optional wireless remote control from an iPad with iOS 7.1, 8.1, or 9. The optional AJ-WM30/WM50 Wireless Module is required for wireless connection.
UPC: 885170348530 In the Box Panasonic AG-UX180 4K Professional Camcorder AG-VBR59 Battery Battery Charger AC Adapter 2 x Power Cord Microphone Holder Kit Eye Cup Lens Hood INPUT Terminal Cap Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Panasonic AG-UX180 4K Professional Camcorder in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersPanasonic AG-UX180 Specs | | | Image Sensor | 1-Chip 1" MOS Sensor | | Sensor Resolution | 4096 x 2160 (9.46 MP) | | Effective Sensor Resolution | 4096 x 2160 (9.46 MP) | | Gain | 0 to 24 dB (Native) | | Sensitivity | f/11 at 2000 lux 89.9% Reflectance When in HIGH SENS. mode | | Minimum Illumination | 0.2 lux at 1/2 Shutter Speed | | White Balance Range | 2000 to 15,000K | | | | Focal Length | 8.8 to 176mm | | 35mm Equivalent Focal Length | 25.4 to 508mm | | Optical Zoom Ratio | 20x | | Max Digital Zoom | 10x | | Maximum Aperture | f/2.8 | | Minimum Aperture | f/4.5 | | Filter Size | 67 mm | | Control Rings | Focus
Zoom
Iris | | Image Stabilization | Optical | | Focus Control | Autofocus
Manual Focus | | | | Shutter Speed | 1/60 to 1/8000 sec | | Scan Rate Adjustable | Yes | | Built-In ND Filter | Mechanical Filter Wheel with Clear, 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters | | Built-In Microphone Type | Stereo | | Recording Media | 2 x SDXC/SDHC UHS-I Card Slots (U1 / Class 10 or faster cards recommended) | | | | Broadcast System Compatibility | NTSC | | Recording Modes | MP4 4:2:0 8-Bit:
4096 x 2160p at 24 fps (100 Mb/s)
3840 x 2160p at 23.98/29.97/59.94 fps (100 to 150 Mb/s)
1920 x 1080p at 23.98/29.97/59.94 fps (50 to 200 Mb/s)
AVCHD 4:2:0 8-Bit:
1920 x 1080p at 23.98/59.94 fps (21 to 25 Mb/s)
1920 x 1080i at 59.94 fps (17 to 21 Mb/s)
1440 x 1080i at 59.94 fps (5 Mb/s)
1280 x 720p at 59.94 fps (8 Mb/s)
720 x 480i at 59.94 fps (9 Mb/s) | | Variable Frame Rates | 1080p: 2 to 60 fps
1080p: 2 to 60 fps
1080p: 2 to 60 fps | | Still Photo | JPEG: 4096 x 2160 (8.8 MP)
JPEG: 3840 x 2160 (8.3 MP)
JPEG: 1920 x 1080 (2.1 MP)
JPEG: 1280 x 720 (0.9 MP) | | Audio Recording | MP4: 2-Channel 16-Bit 48 kHz LPCM Audio
AVCHD: 2-Channel 16-Bit 48 kHz LPCM Audio | | | | Video Connectors | 1 x BNC (3G-SDI) Output
1 x BNC (Composite) Output
1 x HDMI Output | | Audio Connectors | 2 x 3-Pin XLR Mic/Line Level (+48 V Phantom Power) Input
1 x 1/8" / 3.5 mm Stereo Mic/Line Level Output
1 x 1/8" / 3.5 mm Stereo Headphone Output | | Other I/O | 1 x 2.5 mm Camera Interface Control Input
1 x 3.5 mm Camera Interface Control Input
1 x BNC Timecode Data Input/Output
1 x USB Type-A Camera Interface Data Output
1 x USB Micro-B Camera Interface Data Input/Output | | | | Display Type | LCD | | Screen Size | 3.5" | | Touchscreen | No | | Screen Resolution | 1,150,000 Dots | | | | EVF Display Type | OLED | | Screen Size | .39" | | EVF Resolution | 1,770,000 Dots | | | | Battery Type | Panasonic AG-VBR Series Panasonic VW-VBR59 battery | | Power Connectors | 1 x Proprietary (7.2 to 12 VDC) Input | | Power Consumption | 19.7 W | | | | Operating Temperature | 32 to 104°F / 0 to 40°C | | Operating Humidity | 10 to 80% | | | | Accessory Mount | 1 x Cold Shoe Mount | | Tripod Mount | 1/4"-20 Female | | Dimensions | 6.81 x 7.68 x 13.62" / 173 x 195 x 346 mm (Without Protrusions) | | Weight | 4.4 lb / 2 kg | | | | Package Weight | 10.95 lb | | Box Dimensions (LxWxH) | 19.0 x 14.6 x 13.0" |
