User Manual for Panasonic CS-Mount 2.2-6mm f 1.3-T360 DC Auto Iris Lens with Manual Focus and Zoom Click to enlarge the picture
Contents of the user manual for the Panasonic CS-Mount 2.2-6mm f 1.3-T360 DC
- Product category: Lenses Panasonic
- Brand: Panasonic
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Panasonic Lenses
|
User manual for the Panasonic CS-Mount 2.2-6mm f 1.3-T360 DC contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Panasonic product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Panasonic user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Panasonic product will considerably shorten its lifespan!
|
Product description The CS-Mount 2.2-6mm f/1.3-T360 DC Auto Iris Lens from Panasonic is designed for use with megapixel cameras with 1/3" and smaller size sensors. It features manual zoom & focus, 2.7x optical zoom, and the iris value ranges from f/1.3 to T360 (equivalent to f/360). In the Box Panasonic CS-Mount 2.2-6mm f/1.3-T360 DC Auto Iris Lens with Manual Focus and Zoom Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Panasonic CS-Mount 2.2-6mm f 1.3-T360 DC Auto Iris Lens with Manual Focus and Zoom in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersPanasonic PLAMP2206 Specs | Format | CS | | Format | 1/3" | | Focal Length | 2.2 to 6 mm | | Optical Zoom | 2.7x | | Focus Control | Manual | | Zoom Control | Manual | | Iris | f/1.3 to T360 (equivalent to f/360) | | Iris Control | Auto (DC type) | | Back Focus Distance | 7.70 mm in air | | Exit Pupil Position | 452 mm (from image plane) | | Object Dimensions at M.O.D. (HxV) | 4:3 Aspect Ratio:
Wide: 42.32 x 25.12" (107.50 × 63.80 cm)
Tele: 10.47 x 7.72" (26.60 × 19.60 cm)
16:9 Aspect Ratio:
Wide: 52.13 x 18.86" (132.40 × 47.90 cm)
Tele: 11.54 x 6.22" (29.30 x 15.80 cm) | | Angle of View (HxV) | 4:3 Aspect Ratio:
Wide: 120° × 91°36'
Tele: 46°26' × 34°59'
16:9 Aspect Ratio:
Wide: 129°43' × 75°23'
Tele: 50°30' × 28°38' | | Focusing Range | From Front of the Lens: 1.0' (0.3 m) to infinity | | Coil Resistance | Drive Coil: 190 Ω
Damping Coil: 500 Ω | | Current Consumption | 23 mA maximum at 4 VDC | | Weight | 1.9 oz (55.0 g) |
