User Manual for Panasonic Outdoor Camera System with AW-UE70K PTZ Camera Click to enlarge the picture
Contents of the user manual for the Panasonic Outdoor Camera System with AW-UE70K
- Product category: PTZ Cameras Panasonic
- Brand: Panasonic
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Panasonic PTZ Cameras
|
User manual for the Panasonic Outdoor Camera System with AW-UE70K contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Panasonic product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Panasonic user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Panasonic product will considerably shorten its lifespan!
|
Product description The Outdoor Camera System with AW-UE70K PTZ Camera from Panasonic includes a AW-UE70 4K Integrated Day/Night PTZ Indoor Camera and a Dotworkz D2 Heater Blower Enclosure with Multi Volt Platform. The black AW-UE70 4K Integrated Day/Night PTZ Indoor Camera delivers 4K resolution images at 29.97p/25p via HDMI. It is capable of 4K IP streaming and in-camera 4K recording. Equipped with variety of outputs, including 3G-SDI, HDMI, USB, or IP, this camera is suitable for variety of applications such as remote video production, live events, or video conferencing. The Dotworkz D2 Heater Blower Enclosure with MVP is constructed of a rugged polycarbonate thermal plastic alloy material and uses a built-in heater and blower system to shield the camera from the cold and to keep the viewing window from fogging up in humid conditions. The heater is thermostatically controlled while the blower operates continuously. In addition to its internal climate control system, this housing is IP66 rated against dust, water, and salt water air ingress and features IP68 rated connection ports. - AW-UE70 4K Integrated Day/Night PTZ Indoor Camera (Black) The black AW-UE70 4K Integrated Day/Night PTZ Indoor Camera from Panasonic is capable of producing quality 4K and full HD video output and is designed for versatile applications. The AW-UE70 Camera delivers 4K (UHD: 3840 x 2160) resolution images at 29.97p/25p via HDMI, and is also capable of 4K IP streaming, and in-camera 4K recording. Equipped with variety of output including 3G-SDI, HDMI, USB or IP, this camera is suitable for versatile application such as remote video production, live events, or video conferencing.The AW-UE70 Camera also supports PoE+, so the camera only needs one LAN cable for its power supply, control, and video output with embedded audio. Offering a new standard in versatile and high-quality remote video production with IP streaming besides many other powerful features, the AW-UE70 Camera expands the capabilities of integrated camera for professional video system users.
- 4K image quality via HDMI, USB, and IP
-
- 1/2.3-type MOS sensor
- 4K (UHD: 3840 x 2160) video via HDMI, USB, and IP
- 4K / HD IP streaming
- Optical zoom 20x, iA zoom 22x (4K mode) / 30x (HD); digital extender (1.4x, 2.0x, 4.0x, 6.0x, 8.0x)
- Supports HDMI (up to 4K/29.97, 25p) and 3G-SDI (up to 1080/59.94, 60p)
- Single Cable Solution for Remote Video and Audio Capture
-
- Supports PoE+ for lower installation costs
- 4K/HD IP streaming
- Audio embedded
- IP control with image monitoring using PC, Mac and mobile terminals
- Up to 100 cameras can be controlled via IP connection when using network hub
- Powerful features
-
- Wide Angle of View: Horizontal 65.1°
- Optical Image Stabilization (OIS) with gyro sensor
- Freeze during preset function
- ND filter (Auto, thru, 1/4, 1/16, 1/64) and night mode
- USB video class support
- Versatile terminals
- Outputs include 3G-SDI, HDMI, IP, USB (mini B)
- Inputs include genlock, audio (mic/line)
- RS422, RS232C, IP remote control types
- microSD card recording function
UPC: 885170259416 - D2 Heater Blower Enclosure with Multi Volt Platform The Dotworkz D2 Heater Blower Enclosure with MVP is constructed of a rugged polycarbonate thermal plastic alloy material and uses a built-in heater and blower system to shield the camera from the cold and to keep the viewing window from fogging up in humid conditions. The heater is thermostatically controlled while the blower operates continuously. In addition to its internal climate control system, this housing is IP66 rated against dust, water, and salt water air ingress and features IP68 rated connection ports.
This housing can be powered from a 24VAC, 110VAC or 220VAC power source. It also has internal 12VDC and 24VAC outputs to power an IP or analog camera.
This housing is compatible with most analog or IP PTZ dome cameras and has extra room to accommodate peripherals such as encoders, hard drives, routers, etc. A switchable internal mounting mechanism allows top and bottom camera placement for versatile camera positioning and for maximizing internal space. The lower dome is impact resistant and at the same time is optically clear to ensure maximum image sharpness. - IP and analog camera compatible
- Vari-Fit internal bracket included for perfect fit
- Impact resistant polycarbonate thermal plastic
- Thermostatically controlled heater blower system
- IP66 rated against dust, water, and salt water air
- IP68 (waterproof) connection ports
- Onboard Component mounting space for: routers, cell networks, hard drives, UPS, WiMAX, mesh hardware, etc
- Onboard antenna mounting tab
UPC: 853523006031 In the Box Bundle Items AW-UE70 4K Integrated Day/Night PTZ Indoor Camera (Black) tqrsbvcrubyced D2 Heater Blower Enclosure with Multi Volt Platform tqrsbvcrubyced Table of Contents
|
Upload User Manual
Have you got an user manual for the Panasonic Outdoor Camera System with AW-UE70K PTZ Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - AW-UE70 4K Integrated Day/Night PTZ Indoor Camera (Black)
| | | Imaging Sensor | 1/2.3 MOS | | Lens | Optical 20x, f 4.08 to 81.6 mm/F1.8 to 3.6 | | Horizontal Resolution | 1300 TVL (type) (Wide, Center) (4K mode)
1000 TVL (type) (Wide, Center) (HD) | | | | Power | 12 VDC IN, PoE+ (IEEE802.3at standard) | | Audio Input | MIC/LINE (Embedded in SDI/HDMI/IP/USB) | | Video Output | HDMI/SDI/USB | | Interface | LAN/RS-232C/RS-422 remote control | | Output Formats | SDI/HDMI:
2160/29.97, 25p (HDMI only), 1080/59.94p, 50p, 59.94i, 50i, 1080/29.97p, 25p, 1080/29.97psF, 25psF, 720/59.94p, 50p
USB:
3840 x 2160, 1920 x 1080, 1280 x 720, 640 x 360 (M-JPEG) (59.94 Hz) 30p/15p/5p (50 Hz) 25p/12.5p/5p, 3840 x 2160 is 5p | | | | Panning Range | ±175° | | Tilting Range | -30° to 90° | | Image Resolution | 3840 x 2160, 1920 x 1080, 1280 x 720, 640 x 360, 320 x 180 (59.94 Hz) 60p/30p/15p/5p (50 Hz) 50p/25p/12.5p/5p
M-JPEG: 1920 x 1080, 1280 x 720, 640 x 360, 320 x 180 (59.94Hz) 30p/15p/5p (50Hz) 25p/12.5p/5p | | Supported Protocols | IPv4: TCP/IP, UDP/IP, HTTP, DHCP, DNS | | Supported Protocols | AW-RP50, AW-RP120G, AK-HRP200G, AW-RM50G | | | | Power Requirements | 12 VDC (supplied AC adapter)
42 to 57 VDC (PoE+ power supply) | | Current Consumption | 1.3 A (supplied AC adapter)
0.5 A (PoE+ power supply) | | Dimensions | 7.31 x 7.32 x 7.04" (16.0 x 18.6 x 17.9 cm) excluding protrusions, direct ceiling mount bracket | | Weight | Approximately 3.30 lb (1.5 kg) | | | | Box Dimensions (LxWxH) | 13.35 x 12.35 x 11.1" | - D2 Heater Blower Enclosure with Multi Volt Platform
| Mount Type | Wall mount (optional corner, pole brackets available) | | Compatible Cameras | Analog or IP PTZ camera | | Clear or Tinted | Clear | | Construction | Housing: Dotworkz thermoplastic alloy
Bubble: Precision view high impact acrylic | | Enclosure Rating | IP66 with IP68 connection ports | | Operating Temperature | Absolute: -25 ~ +140°F (-32 ~ +60°C)
Recommended: 0 ~ 120°F (-17 ~ +49°C) | | Power Input | 24VAC, 110VAC, or 220VAC | | Power Output | (to camera)
IP: 12VDC, 24VDC
AC (CCTV): 12VDC, 24VAC | | Power Consumption | 2 amps @ 115VAC typical at full load | | Dimensions (WxHxD) | 11.7 x 13.4 x 14.9" (297 x 340 x 378mm) | | | | Box Dimensions (LxWxH) | 17.2 x 15.9 x 13.0" |
