User Manual for Panasonic UE70 Outdoor Cooling System with Cooled Outdoor Enclosure, AW-UE70 4K PTZ Indoor Camera, and Teradek Cube 255 Encoder Click to enlarge the picture
Contents of the user manual for the Panasonic UE70 Outdoor Cooling System with
- Product category: PTZ Cameras Panasonic
- Brand: Panasonic
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Panasonic PTZ Cameras
|
User manual for the Panasonic UE70 Outdoor Cooling System with contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Panasonic product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Panasonic user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Panasonic product will considerably shorten its lifespan!
|
Product description The UE70 Outdoor Cooling System from Panasonic comes equipped with active cooling outdoor enclosure, AW-UE70K PTZ camera, and Teradek Cube 255 Encoder.
The D2-CD CoolDome Enclosure is designed with an active on-board and thermostatically controlled air conditioning, to protect the camera and the encoder. The enclosure uses solid state cooling technology which takes protection to the next level for climates where temperatures exceed 105°F (41°C) and reach as high as 167°F (75°C).
The AW-UE70K Integrated Day/Night PTZ Indoor Camera is capable of producing quality 4K and full HD video output and is designed for versatile applications. The camera delivers 4K (UHD: 3840 x 2160) resolution images at 29.97p/25p via HDMI, and is also capable of 4K IP streaming, and in-camera 4K recording. Equipped with a variety of outputs including 3G-SDI, HDMI, USB or IP, this camera is suitable for versatile application such as remote video production, live events, or video conferencing.
The Teradek Cube 255 HDMI Encoder with Wi-Fi is a wireless camera-top video and embedded audio encoder. It connects to a camera by HDMI and streams proxy files/dailies in H.264 to a decoder or website. You can stream by dual-band Wi-Fi wherever a network is available, by Ethernet via an optional router, or by an optional 3G/4G modem connection. - Enclosure
-
- Thermostatically controlled Active Cooling technology
- Virtually indestructible Polycarbonate Thermal Plastic alloy material
- Integrated Dual Layer (Foil/Foam) internal thermo-blanket protects electronics from solar-heat and UV Rays to reduce solar-loading and protects from cold weather conditions, creating a stable internal camera environment
- Internal bracket included
- Switchable upper and lower camera mounting locations for maximum versatility and internal storage space utilization
- Internal mounting space
- IP66 Rated: Airtight and sealed against outside air, dust, water and salt water
- Includes IP68 waterproof connection ports
In the Box Panasonic UE70 Outdoor Cooling System with Cooled Outdoor Enclosure, AW-UE70 4K PTZ Indoor Camera, and Teradek Cube 255 Encoder Cooled Outdoor Enclosure AW-UE70 4K Integrated Day/Night PTZ Indoor Camera (Black) Cube 255 HDMI Encoder with Wi-Fi Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Panasonic UE70 Outdoor Cooling System with Cooled Outdoor Enclosure, AW-UE70 4K PTZ Indoor Camera, and Teradek Cube 255 Encoder in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersPanasonic AW-UE70 Specs | | | Operating Temperature | Absolute/Rec: -40 to 167°F (-40 to 75°C)
30 to 145°F (-1 to 63°C) | | Power Consumption | 9 A @ 12 VDC typical at full load | | Power Source | Input: 12 VDC, 110 or 220 VAC | | Output Power | Camera: 12 VDC | | Internal Power | Camera: 3 A @ 12 VDC on typical model | | Dimensions | 17 x 13 x 16" (43.2 x 33.0 x 40.6 cm) | | Weight | 15 lb (6.8 Kg) |
