Product description The WV-ASM300W i-Pro Video Management Software from Panasonic offers control and integration of i-PRO Extreme H.265 & i-PRO H.264 equipment. This VMS connects up to 100 NVRs and DVRs, as well as 64 encoders and 256 cameras. - Integrates i-PRO Extreme H.265 & i-PRO H.264 equipment
- Offers camera control, viewing, and recorder management
- Directly connect up to 100 recorders, 64 encoders, and 256 cameras
- Up to 6400 cameras registered in the recorders & 256 cameras registered in the encoders are indexed in the software automatically
- Supports 16:9, 4:3, and 9:16 corridor format aspect ratio video streams to be displayed on the same monitor
- 4K native graphical user interface
- Auto camera configuration wizard for quick system setup
- End-to-end AES-256 encryption
- Camera SD card full-encryption-video-recording on the edge can be downloaded and decrypted securely
- No fees or licenses required for trials
- Supports multi-monitor and WV-CU950 universal system controller
- Full array of software extension modules
Table of Contents
|
Upload User Manual
Have you got an user manual for the Panasonic WV-ASM300W i-Pro Video Management Software in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersPanasonic WV-ASM300W Specs | Functions | Live/playback/control | | Compatibility | i-PRO Extreme H.265 & i-PRO H.264 equipment
NVRs: WJ-NX400, WJ-ND400 Series, WJ-NV300, WJ-NV200 Series, WJ-ND300 Series, WJ-ND200 Series
DVRs: WJ-HD716/616, WJ-HD300A Series
Encoders: WJ-GXE500, WJ-GXE100
Controller: WV-CU950 | | Maximum Number of Devices | Camera Direct: 256
Camera via Recorder: 6400 with WJ-NX400 & WJ-ND400 Series, 3200 with WJ-ND300 Series, 1600 with WJ-ND200 & WJ-NV200 Series
Via Encoder: 256 with WJ-GXE500, WJ-GXE100
Recorder: 100
Encoder: 64
Controller: 1 | | Supported Image Formats | H.265, H.264, MPEG-4 (i-PRO series), MJPEG (depending on the source equipment) | | Image Resolution | Supported Image Resolution: Depending on the source equipment (current i-PRO network cameras, encoders) | | Number of Screens | Maximum 20 | | Monitors Supported | Multiple Monitors Supported:
Up to 3 Monitors: Operation / Live / Map | | Map Function | Yes | | Audio | Live: Two-Way
Playback: One-Way | | Event Search | Yes | | Video Motion Detection | VMD search with WJ-NX400, WJ-ND400 series, WJ-HD716/616, WJ-NV300, and WJ-NV200 | | Image Download | Yes | | Camera Control | Camera control depending on camera
Pan/tilt, zoom, focus, brightness, preset position call and program (up to 256), auto mode (seq, sort, auto pan, patrol, auto track), aux 1-3, click centering, wheel zoom, drag and zoom | | Recorder Control | Recorder control depending on camera
Rec, play, rev play, pause, stop, FF (up to 96x), rew (up to 96x), prev record, next record, prev image, next image, skip (up to 60 minutes), rev skip (up to 60 minutes), text | | Event Search | Target: Recorder (Camera), Group, Map
Search Criteria: Time/Date, Event Type, Text | | VMD Search | Target: Recorder (Camera)
Search Criteria: Time/Date, Area
In case with WJ-ND400 series, WJ-HD716/616, WJ-NV200 | | Thumbnail Search | Target: Camera
Search Criteria: Time/Date, Stream, Interval | | Multi-Screen Mode | 1, 2, 3, 4, 5, 6, 7, 10, 13, 16 split | | Sequence | Sequence Display:
20 programs, 64 steps/pattern, 1, 2, 3, 4, 5, 6, 7, 10, 13, 16 split
Dwell Time:
3, 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55 seconds
1 minute | | Display Performance | 30 fps x 16 screens at H.264, 1.5 Mb/s
30 fps x 16 screens at MPEG-4, 2 Mb/s
30 fps x 16 screens at H.265, 768 kb/s (VGA) | | Multi-Monitor | Up to 3 monitors (operation, live, map)
Up to 20 cameras can be displayed (4 operation, 16 live) | | Camera Group Display | Up to 400 groups with 16 alphanumeric titles | | Maps | Up to 100 maps (JPEG or bitmap)
Link: 128 Cameras and 20 Maps/Map | | Image Download | Recorded images of up to 64 cameras (in the case with WJ-ND400) can be downloaded manually only
Viewer software can be extracted from the main software | | Quick Download | Quick download the operation monitor image | | SD Memory Data Download | Indicates the function featured in some Panasonic cameras that transfers H.264/H.265 video files (MP4 files) saved on the SD memory card equipped with the camera to a PC using the FTP function | | Access | Recorder/Camera Access:
The access to the recorder and camera web pages when logged in as admin | | File Conversion | Convert a N3R file to the standard format (MP4) | | Title Display | Camera Title Display:
On the GUI, up to 16 characters | | Clock Display | On the GUI
Time: 12/24 Hours
Date: 5 Formats (when the image comes from the recorder) | | Alarm Source | Panasonic alarm protocol | | Alarm Control | Reset, auto reset (off, 10/20/30 seconds, 1/5 minutes) | | Alarm Actions | Up to 16 alarm images can be displayed on the live monitor
Corresponding camera icon on the map lights up
Alarm message on the GUI and buzzer | | Digital Zoom | 4x | | Text Attachment | Free comment can be attached for each record and reviewed at later time
Up to 200 characters | | System Log | Operation (100,000), system (1000), network error (1000), recorder error (1000), alarm (30,000) | | Log | Recorder Log Download:
Operator access, network error, error, event | | User Management | Registration:
Up to 32 users + administrator
ID: 4-32 Digit
Password: 8-32 Digit
User Level: 6 Programmable Levels
Password Time Limit: Off, 31/92/184/366 Days
Auto Login: On/Off | | Security | User authentication (ID and password), host authentication (IP address), alteration detection, activation key card | | System Setup | Setup page in English, French, Italian, Spanish, German, Russian, Chinese, Thai, Japanese | | GUI Language | English, French, Italian, Spanish, German, Russian, Chinese, Thai, Japanese | | Supported Operating Systems | Microsoft Windows 10 Pro 32-bit/64-bit, 8.1 Pro 32-bit/64-bit, 7 Professional SP1 32-bit/64-bit (language of the OS must be same as selected GUI language)
4K cameras (WV-SFV781L/WV-SPV781L) are available only on Windows 10 Pro 64-bit and Windows 8.1 Pro 64-bit | | CPU Requirements | Intel Core i5-6500, Intel Core i7-6700 or faster
Intel Core i7-6700 or faster when adding the license for WV-ASE202 and displaying images on 64 screens
Intel Core i7-6700 or faster when adding the license for WV-ASE205 (visibility enhancement function, recommendation exclusively for WV-ASE205)
Intel Core i7-6700 or faster when using WV-SNR10 and WV-SNR10N3 network microphones
Intel Core i7-6700 or faster when using WV-SFV481 and WV-SFN480 9 MP network cameras
Intel Core i7-6700 or faster when using WV-SFV781L and WV-SPV781L 4K network cameras
Intel Core i7-6700 or faster when using a H.265 camera | | Memory Requirements | 4 GB or more
8 GB or more when using WV-SFV481 and WV-SFN480 9 MP network cameras
8 GB or more when using WV-SFV781L and WV-SPV781L 4K network cameras
8 GB or more when using a H.265 camera | | Graphics Chip | VRAM:
512 MB or more, compatible with Microsoft DirectX 9.0c or later
2 x NVIDIA NVS510 when using WV-ASE202
NVIDIA GeForce GTX 660 or more when using WV-ASE205 (visibility enhancement function)
GeForce 332.21 or later is recommended for the driver software
NVIDIA NVS 510 when using a 4K monitor
To display 4K/2K resolution on a monitor at 60 Hz, connection on the display port 1.2 is required | | CD-ROM | CD-ROM drive necessary to install software | | HDD | Required HDD Space: Approximately 3 GB | | Monitor | 1280 x 800 pixels or more (1920 x 1080 recommended)
24-bit true color or better (full color recommended) | | Network Interface | 100/1000M Ethernet port | | Supported Web Browsers | Microsoft Internet Explorer 7, 8, 9 | | Proxy | HTTP proxy supported (IP address and port number) | | FTP | Passive, active | | Playback Control | Play, rev play, pause, FF, rew, prev record, next record, prev image, next image | | Additional Functions | Alteration detection, save as JPEG, 2x zoom, print |
