User Manual for Panasonic WV-V1330L1 2MP Outdoor Network Box Camera with Night Vision & 2.7-12mm Lens Click to enlarge the picture
Contents of the user manual for the Panasonic WV-V1330L1 2MP Outdoor Network Box
- Product category: Wired IP Cameras Panasonic
- Brand: Panasonic
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Panasonic Wired IP Cameras
|
User manual for the Panasonic WV-V1330L1 2MP Outdoor Network Box contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Panasonic product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Panasonic user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Panasonic product will considerably shorten its lifespan!
|
Product description The WV-V1330L1 2MP Outdoor Network Box Camera from Panasonic features a high-performance CMOS image sensor and 2.7-12mm varifocal lens. It supports H.265, H.264, and MJPEG triple-stream encoding and a resolution of 1920 x 1080 at 30 fps. It also features an ICR for day and nighttime operation and IR LEDs with a maximum range of 196'. In the Box Panasonic WV-V1330L1 2MP Outdoor Network Box Camera with Night Vision & 2.7-12mm Lens Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Panasonic WV-V1330L1 2MP Outdoor Network Box Camera with Night Vision & 2.7-12mm Lens in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersPanasonic WV-V1330L1 Specs | | | Image Sensor | Approximately 1/2.8" type CMOS image sensor | | Minimum Illumination | 0.2 lux at f/1.4 (color)
0 lux f/1.4 (IR on) | | Gain | Auto/Manual | | Back Light Compensation | Off/BLC/HLC/WDR | | Shutter Speed | Auto/Manual, 1/3 sec to 1/100,000 sec | | Day and Night | Auto (ICR) / Color / B&W | | IR LED Range | 196' / 60 m | | White Balance | Auto/natural/streetlamp/outdoor/manual | | Digital Noise Reduction | 3D-DNR On/Off | | Privacy Masking | Up to 4 areas | | Video Motion Detection | On/Off (4 zones, rectangle) | | Tamper Detection | On/Off | | | | Zoom Ratio | 4.4x Optical (Motorized zoom/focus) | | Focal Length | 2.7-12mm | | Angular Field of View | H: 99 to 37°
V: 52 to 21° | | | | Network | 10Base-T/100Base-TX, RJ45 connector | | Resolution | 1080p (1920 x 1080) / 1.3 MP (1280 x 960) / 720p (1280 x 720) / 640 x 480 / 640 x 360 / 320 x 240 | | Image Compression | H.265/H.264/MJPEG | | Frame Rate | 1 to 25/30 fps | | Protocol | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, DDNS, FTP, QoS, 802.1x | | Maximum Concurrent Access Number | 20 users | | Compatible Card Slots | 4 to 128 GB (microSDXC/SDHC memory card, sold separately) | | | | Power Source | 12 VDC, PoE (IEEE 802.3af compliant) | | Power Consumption | 12 VDC: 1 A / Approximately 12 W
PoE 48 VDC: 230 mA / Approximately 11 W
(Class 0 device) | | Operating Temperature / Humidity | -22 to 140°F / -30 to 60°C
10 to 90% (no condensation) | | Water and Dust Resistance | IP66 | | Dimensions | 3.5 x 3.5 x 8.4" / 90 x 90 x 214 mm | | Weight | Approximately 1.54 lb / 0.69 kg |
